Atomos Ninja Stream
Click to enlarge
Home » Shop » Pro-Video » Video Recorder » 4K Recorder » Atomos Ninja Stream Capture, Encode & Stream Simultaneously
Atomos Ninja V+ HDR Monitor-Recorder
Atomos Ninja V+ 8K RAW HDR Monitor Recorder USD 799.00 – USD 1,299.00 excl. Tax
Back to products
Mackie CR5-X
Mackie CR5-X 5-inch Creative Reference Multimedia Monitor / Speaker USD 222.00 – USD 241.00 excl. Tax

Atomos Ninja Stream Capture, Encode & Stream Simultaneously

Atomos
Add to wishlist
26 People watching this product now!
Category: 4K Recorder
Share:
  • Description
  • Specifications
  • In The Box
  • Delivery Info
  • Reviews (0)
Description

Atomos Ninja Stream Capture, Encode & Stream Simultaneously

The Atomos Ninja Stream was designed specifically to overcome the challenges of today’s socially distanced productions and is a 5” 4Kp60 HDR Monitor-Recorder-Streamer with HDMI I/O, 5.8G Wi-Fi, 1G Ethernet and USB-C 3.0 to usher in a new era of streaming on productions without the need for any computers.

Ninja-Stream

High quality Log or HDR video feeds can be simultaneous recorded in both ProRes and H.265/4 to the Ninja’s SSD. The Atomos Ninja Stream also allows you to output a variety of formats to the SSD, over Wi-Fi and Ethernet and to the cloud at the same time including 4KDCI, UHD, HD and 720p. Standards conversion allows you to up convert and down convert between resolutions as well.

Live distance production starts with the 5.8G Wi-Fi, allowing H.265 10-bit 422 HDR to be remotely monitored at up to 300m in HD or 75m in 4K. This can be received on a companion Ninja Stream, and output to any monitor over the HDMI out in 4K or instantly connected to phones and tablets for client and stakeholder viewing on-set.

Stream your own way

Atomos Ninja Stream powerful streaming options allow for up to 8 Streams at 720p over each connection of WiFi x 1, Ethernet x 2 and USB 4G/5G* x 1 ( At 4Kp60, 4 streams can be achieved).

The network preset configurations are categorized in the menu system as One-to-One, Many-to-One, One-to-Many, Many-to-Many. These can facilitate direct streaming to cloud platforms or to other networked devices.

One-to-One

Atomos Ninja Stream Stream up to 4Kp60 10-bit HDR quality, direct to Cloud, Computers, Apple TV, iPhones, iPads, Android devices** or another Ninja Stream.

Many-to-One

Quad-view mode for directors, allowing multiple Ninja Stream sources to be viewed from a single Ninja Stream for monitoring.

One-to-Many

Stream from one Ninja Stream to other devices over Wifi, Ethernet and 4G/5G* simultaneously.

Many-to-Many

Access any device from any connected device on set – Cloud, Computers, Apple TV, iPhones, iPads, Android devices** or another Ninja Stream.

* 4G/5G mobile network connections require a phone or USB Mobile Network Dongle.
** App required to receive stream.

Simultaneous Codec Recording

Atomos Ninja Stream Record an editing codec like Apple ProRes HQ whilst recording an H.265 or H.264 proxy version at the same time. Both the edit and proxy files will share file names and timecode to facilitate the proxy workflow in post-production.

The 10-bit H.265 file provides excellent image quality with a small file size, whereas the 8-bit H.264 file provides compatibility with legacy consumer and video equipment – yes you can monitor on your 2010 iPhone or Android device.

The excellent image quality is maintained on the disk, and small file sizes mean you can share or deliver your files immediately after a shoot in their pristine form. Uploads are fast, and viewing compatibility is high on the receiving device.

Monitoring and Recording

In addition to all of these incredible features, you also have all of the amazing features of the award-winning Ninja V, which gives you a rock-solid monitor-recorder that records to affordable SSD media with class-leading high brightness HDR monitoring technology.

The Atomos Ninja Stream 5.2” 1920 x 1080 LCD IPS screen boasts 1000nits output for daylight use, whilst the AtomHDR engine allows users to see Log images in High Dynamic Range or load creative LUTs at the touch of a button. In terms of scopes,

Ninja Stream gives you all the critical monitoring tools you need, including histogram, false color, focus peaking, 1x and 2x zoom magnification, waveform, RGB parade, Vector scope, zebra, Cine frame guides, anamorphic de-squeeze and more.

The scopes can be used during playback for critical footage review and both playout and loop through is possible for review on larger screens. The build quality is what you would expect from Atomos with an Aluminium body and active cooling system on board to ensure you are never let down in the field.

Atomos Ninja Stream allows you to record up to 4Kp60 in either Apple ProRes (Proxy, LT, 422, HQ), H.264 (up to 8-bit) or H.265 (up to 10-bit). These compressed codecs give users more flexibility with recording times and reduces the media cost during capture, backup and archiving.

Specifications
Physical Specifications
Dimensions (W x H x D mm) 144 x 84.5 x 31.4
Weight 364g / 12.8oz (exc. antenna)
Mount points 1 x Anti rotation 1/4″ + 3/8″ top and bottom
Environmental
Ambient operating temperature -20 to +40° C
Construction and Control
Body Aluminium and ABS
Cooling Active
Tally light Rear and Side
Control Buttons Assignable Function Button
Multi-function button Assignable
AtomXpansion slot No
Power
Input voltage 100-240 V
Operating power 15 Watts
Compatible batteries NPF L series
Built in battery No
Battery voltage 5.8 – 14.4V
Battery Run time (Record) 5200mAh – up to 4hrs (Rec, Play, Mon, Stream @ 4K 60p) 7800mAh – up to 6hrs (Rec, Play, Mon, Stream @4K 60p)
Continuous power Via Optional AtomX SYNC Module
DC in connector Via Battery Eliminator
Dtap Via Battery Eliminator and optional DTap to DC cable
DC out USB-C out 5V
Display
Touchscreen Capacitive
Size 5.1″
Resolution 1920 x 1080
Viewing angle 175°
Screen coating Anti-Fingerprint and AR Coating
PPI 427
Bit depth 10-Bit (8+2 FRC)
Backlight Type Edge lit
Brightness (cdm2 / nits) 1000
Aspect ratio 16:9
Color Gamut Rec.709
Calibration support Atomos Calibrator with Xrite i1 Display Pro / Plus (Retail)
Color Pipeline
Gamma Sony SLog / SLog2 / SLog3, Canon CLog / CLog2 / Clog3,Arri Log CEI160 / LogCEI200 / LogCEI250 / LogCEI320/ LogCEI400 / LogCEI500 / LogCEI640 / LogCEI800 /LogCEI1000 / LogCEI1280 / LogCEI1600, Panasonic Vlog,JVC JLog1, Red LogFilm / Log3G10 / Log3G12, FujiFilmFlog, PQ (HDR10), HLG, Nikon N-Log
Gamut BT2020, DCI P3, DCI p3 65, Sony SGamut / SGamut3 / SGamut3.cine / Canon Cinema / DCI P3 / DCI P3+ / BT2020Panasonic V GamutArri Alexa Wide GamutRec709JVC LS300Red DragonColor / DragonColor2 / RedColor2 /RedColor3 / RedColor4 / RedWideGamut
3D LUT Display .Cube Format (Display only)
3D LUT Down Stream No
3DLUT 50/50 Yes
Monitoring Modes Native / HLG / PQ / 3D LUT
HDR output Conversion Log / HDR to HLG / PQ
Video Input
HDMI 1 x HDMI (2.0) 4k p60
RJ45 / Network 2 Channels over single RJ45
Wifi Hotspot and Client Modes supported
USB USB-C 3.0
Bit Depth Up to 10-bit
Video Chroma Subsampling 4:2:2
HDCP copy protection No supported
Metadata
HDMI Yes – Start/Stop Trigger, Timecode and HDR
Video Output
HDMI 1 x HDMI (2.0) 4k p60 (limited 1920×1080 when recording in ProRes HQ or 422)
RJ45 / Network Ethernet Router
Wifi Wifi Router
Multiview 4 x Ninja Streams to one Ninja Stream only
OS overlays Yes
Video Chroma Subsampling 4:2:2
Bit Depth 10-bit Video
Web Streaming
USB UVC No
RJ45 / Network Yes
RTMP / S Yes
RTSP Yes
SRT Yes
Video Signal Conversion
HDMI to SDI No
SDI to HDMI No
Audio In/Out
Audio Quality 24/48kHz
Audio Codec PCM or ACC
HDMI 8ch 24-bit, input dependent
Analogue Audio in Line level and Mic level input
Analogue Audio Out Yes 3.5mm Connector
Speakers No
Headphone out 3.5mm 2ch.
Timecode / Sync
Embedded HDMI
Time of day Yes, Time and Date, Wi-Fi sync
LTC via 3.5mm audio Jack input (requires post processing)
Wireless SYNC Via Optional Atomos UltraSync Blue
Resolution and Frame Rates (Record, Monitor & Playback)
4k DCI 23.98/24/25/29.9/30/50/59.94/60p
4k UHD 23.98/24/25/29.9/30/50/59.94/60p
2K DCI 2046 x 1080 23.98/24/25/29.9/30/50/59.94/60p
FHD 1920 x 1080 Progressive 23.98/24/25/29.9/30/50/59.94/60/100/120p
FHD 1920 x 1080 PsF converted to P and looped out PsF
FHD 1920 x 1080 Interlaced 23.98/24/25/29.9/30/50/59.94/60i
1280 x 720p 50/59.94/60p
Recording CODEC
CDNG No
Apple ProRes RAW No
Apple ProRes Proxy, LT, 422, HQ
H.265 Low / Medium / High
H.264 Low / Medium / High
Playback
Playlist Yes
Loop Yes
CDNG No
Apple ProRes Raw No
Apple ProRes Proxy, LT, 422, HQ
H.265 Yes
H.264 Yes
Recording functions
Pre-roll record Yes (HD 8s, 4K 2s)
ISO Record No
Switched Program Record No
Timelapse Yes
RAW to Video Record No
Simultaneous proxy record Yes
4k to HD Yes I/O
Multi Input / Switching
SDI A/B toggle No
Dual Input display –
Multiple SDI input No
Multiview Display 4 – From Ninja Streams only
Multiview Ouput Monitor only
Supported media
Master Caddy I Yes
SSDmini Yes
CFast II With CFast Adapter
SD No
USB No
File Naming Unit name / Append Data / Data & Time
File System ExFAT, FAT32
On screen tools
MultiScope Analysis View Yes
Waveform Yes
Histogram Yes
RGB parade Yes
Vector scope Yes
1 x Zoom Yes. 1:1 Pixel mapping for 4k
2 x Zoom Yes
Focus peaking Colour selected / threshold setting / color / mono / edges only
False colour Yes
Zebra High and low
Isolate color channel R / G / B / Luma
Cine Frame Guides 2.4:1, 2.35:1, 1.9:1, 1.85:1, 4:3
Safe areas Action and Graphic
Grid markers 9 grid and crosshair with color selection
Anamorphic desqueeze 1.33x, 1.5x, 1.8x ,2x
Display Flip No
Onboard Signal Processing
Pulldown Removal Yes
4K UHD Downscale for HD Yes
DCI Crop Loop out – 17:9 to 16:9 Crop
Remote control
HDMI Auto HDMI Trigger, Supported Protocols – Canon, Sony,Atomos Open Standard
Serial 2.5mm Jack LANC control and calibration via optional USB to serial cable
External Device Control
Supported Applications
XML Cut tag EDL in FCPX XML
Video Codecs All applications with support for Apple ProRes and Avid DNX in .MOV wrapper
In The Box
  • Ninja V
  • 1 x Battery eliminator
  • 1 x international DC power supply
  • 1 x MasterCaddy II
  • QuickStart Guide
Delivery Info

How to shop TAX free in Singapore

8% Goods Service Tax (GST) will be imposed over the total invoice value if purchased locally in Singapore. However if you are a tourist visiting Singapore, this GST amount can be refunded at the Changi International Airport Departure Hall GST Refund Centre before departure with goods within 60 days from the date of purchase. Please note that only Tourists who have met the Tourist Refund Scheme’s conditions and eligibility criteria can claim for the GST refund. Visit the following link for GST Guide for Visitors on Tourist Refund Scheme. https://www.iras.gov.sg/taxes/goods-services-tax-(gst)/consumers/tourist-refund-scheme


All items that are available for purchase online are subjected to availability. For item that are available, a confirmation email will be sent to your registered email to show that your order had been processed and is ready for collection / to be delivered. In the event whereby the item ordered is unavailable, a notification email will be sent and refund will be initiated immediately.

Self-collect: Item will be ready for collection at our store once the confirmation email is received. Orders that are made on the Weekends or Public Holiday may take about 2-4 working days to process.

Delivery (Local, Singapore): Small items: Delivery will take approximately 3-5 working days (excluding weekends and public holidays) to be delivered upon confirmation of order. Orders will be delivered by Singpost or local couriers.

Large / Bulky items: Delivery will take approximately 7-10 working days (excluding weekends and public holidays) to be delivered upon confirmation of order. Orders will be delivered by Expandore.

Delivery (Overseas); Shipment will be arranged with our courier partners to be delivered to your shipping address.

If you have other inquiries for placing of order and delivery, you can refer to our FAQ here (https://www.expandore.sg/faq/) Or Contact us here (https://www.expandore.sg/contact-us/)

Reviews (0)

Reviews

There are no reviews yet.

Only logged in customers who have purchased this product may leave a review.
