AVMatrix SHARK S6 6-Channel HDMI & SDI Multi-Format Video Switcher
SGD 1,341.23 excl. Tax
Product Highlights:
- Built-in 5-inch LCD display
- Input: 4×SDI and 2×HDMI
- Output: 2×SDI, 1×HDMI PGM, 2×SDI AUX, 1×HDMI Multiview, 1×USB Type-C
- RTMP stream & USB Disk & SD Card Record
- USB for capturing and streaming on PC
- Professional chroma Key, downstream key, 2PIP/POP, and LOGO overlay
- Layout style: landscape & portrait mode
Weight | 6 kg |
---|
AVMatrix SHARK S6 5-inch LCD Display Multi-Camera All-In-One Video Switcher for Live Stream and Broadcast Device
AVMatrix SHARK S6 is a 6-channel HDMI & SDI multi-format video switcher with a 5-inch LCD display. It supports functions like LAN streaming, recording, video switching, audio mixing, PGM/Multiview/AUX out, different transition effects, Chroma Key, DSK, LOGO, PIP/POP, PTZ control, etc.
- Built-in 5-inch LCD display
- Input: 4×SDI and 2×HDMI
- Output: 2×SDI, 1×HDMI PGM, 2×SDI AUX, 1×HDMI Multiview, 1×USB Type-C,
- Professional chroma Key, downstream key, 2PIP/POP, and LOGO overlay
- T-bar/Auto/Cut transitions, various effects: MIX/DIP/WIPE effects
- FTB/STILL, GPIO port for the tally system, RS232/RS422/RS485
- Multiview layout style: Landscape and portrait mode
- RTMP stream & USB disk/SD card record
- USB-C for capturing and streaming on PC
- Audio mixer: 4×SDI, 2×HDMI audio & 2×MIC in
- PTZ camera control: VISCA, VISCA over IP, PELCO & ONVIF protocols
Live Stream Via Ethernet
The LAN port supports IP streaming transmission through the RTMP(S), RTSP, & SRT protocols, allowing users to easily live stream video programs to platforms such as YouTube, Skype, Facebook, and Twitch and get high-quality videos.
USB Disk & SD Card Record
SD card and USB interface enable direct recording of PGM signal, making it easy to record high-quality videos. The bitrate of encoding is up to 32 Mbps, and the supported file formats are MP4/TS.
USB Capture for Streaming
The USB type-C can be used as a webcam to capture video & audio and stream to various software & platforms such as OBS, VMIX, ZOOM, Teams, Skype, and VLC. It is compatible with Windows, Linux, and Mac.
PTZ Camera Control
With the PTZ control feature, users can easily pan, tilt, and zoom PTZ cameras using LAN and RS-232/RS-422/RS-485. Camera control protocol supports VISCA, VISCA over IP, Pelco D/P, and ONVIF.
Versatile Input & Output
The video switcher includes 4 SDI & 2 HDMI inputs; 2 SDI & 1 HDMI PGM outputs, 1 HDMI Multiview output, and 2 SDI AUX outputs, which allow users to configure the output from IN 1-6, PGM, PVW, Multiview, etc.
Built-in 5-inch Display
A 5-inch HD display provides a multiview with real-time monitoring of 6 channel inputs, menu operation, and streaming/recording status.
Landscape & Portrait Mode
The video switcher provides both portrait and landscape modes for multiview output; users can choose the layout they need according to different event production application fields.
Professional Audio Mixer
The switcher’s integrated audio mixer enhances the audio effect of your productions by combining two external MIC inputs and 6 input-embedded audio. Users can also set the AFV and utilize the audio delay feature to ensure audio-video synchronization.
Upgraded Chroma Key
Enhanced chroma key technology delivers precise background removal for virtual studios and live events.
Widespread Application
The video switcher can be widely used in various field events, such as live sports, virtual studios, Education, the internet, concerts, etc.
To view more AVMATRIX Products
View more HDMI Switcher Products
Related Products in .biz:
CONNECTION:
- Video In: SD/HD/3G-SDI (75Ω) ×4, HDMI type-A (100Ω) ×2
- PGM Outputs: HD/3G-SDI (75Ω) ×2, HDMI Type-A (100Ω) ×1
- Multiview Outputs: HDMI type-A (100Ω) ×1
- AUX Outputs: 3G-SDI (75Ω) ×2, including IN1~6, PVW, PGM, Color Bar, and Multiview
- Stream Output: LAN
- Capture Output: USB type-C
- Audio Input: MIC ×2
- Audio Output: Line ×1, Earphone slot ×1
- Media Port: USB type-A × 1
- Camera Control Port: LAN, RS232/RS422/RS485
- Tally Port: DB-15
- Power In: DC 12V
STREAM & REC:
- Bitrate: 2M~32Mbps
- Rate Control: CBR/VBR
- Stream Protocols: RTMP(S)/RTSP/SRT
- REC SD Card Format: FAT32/exFAT/NTFS
- REC USB Disk Format: FAT32/exFAT/NTFS
- REC File segment: 1~120 mins
FUNCTIONS:
- Transitions: T-Bar/ AUTO/ CUT
- Effects: WIPE(11×3 patterns)/ MIX/ DIP/ STILL(freeze)/ FTB
- Multiview Layout: Landscape & Portrait Mode
- Upstream Key: Chroma Key ×1, PIP ×2/ POP×1
- Downstream Key: DSK ×1, Logo ×1
- Audio Function: AFV, Mix, Audio delay
- Logo Library: Up to 8 PNG images
- Record Storage: USB Disk/SD Card
- Display: 5-inch HD LCD Display
STANDARDS:
- SDI Input Format Support: 1080p 60/59.94/50
1080p 30/29.97/25/24/23.98, 1080psF 30/29.97/25/24/23.98
1080i 60/59.94/50
720p 60/59.94/50/30/29.97/25/24/23.98
625i 50 PAL, 525i 59.94 NTSC - HDMI Input Format Support: 1200p 60/50/30
1080p 60/59.94/50/30/29.97/25/24/23.98/23.976
1080i 50/59.94/60
720p 60/59.94/50/30/29.97/25/24/23.98
576i 50, 576p 50 - PGM Output Format: 1080p 60/59.94/50/30/29.97/25/24/23.98
1080i 60/50/59.94 - Multiview Output Format: 1080p 60
- Color Space: RGB Full/RGB Limited/YUV
- SDI Video Rate: Auto Detection, SD/HD/3G-SDI
- SDI Compliance: SMPTE 292M/SMPTE 259M/SMPTE 424M
- USB Capture Out: MJPG, up to 1080p 60
- Supports OS: Windows 7/8/10/11, Linux (Kernel version 2.6.38 and above), Mac OS (10.8 and above)
- Capture Compatibility: OBS Studio, Skype, ZOOM, Teams, YouTube, Live, etc.
OTHERS:
- Consumption: ≤20.4W (12V 1.7A)
- Dimension (LWD): 238.5 × 168.2 × 47.5 mm
- Weight: Net Weight: 1450g, Gross Weight: 2370g
- Temperature: Working: -20℃~60℃, Storage: -30℃~70℃
