BirdDog X1 PTZ Camera with Optical 20x Zoom

SGD 1,349.45 excl. Tax

Product Highlights:

  • 20x Zoom & UHD 4K30 Resolution
  • Integrated 2.93″ E-Ink Display
  • HDMI & USB/UVC Outputs
  • Wi-Fi 5 & NDI|HX3 Support
  • Built-In Halo Tally
  • Support Color Matrix, API & Kelvin Control
  • Exceptional Low-Light Performance
Weight N/A
Choose the Product Variant

Black

,

White

SKU: N/A Category:
Description
Click to rate this post!
[Total: 1 Average: 5]

BirdDog X1 20x Zoom PTZ Camera with AI Auto-Framing and Low-Light Performance

Capture 1080p60 video with AI auto-framing that keeps subjects centered using BirdDog’s X1 PTZ Camera with 20x Zoom. The BirdDog X1 PTZ Camera model is equipped with a robust 20x optical zoom, precise color matrix, API, and Kelvin control, ensuring excellent low-light performance. It supports Wi-Fi 5 and NDI|HX3 for seamless network integration.

Flexible Connectivity

Connect directly to platforms like Microsoft Teams and Zoom via HDMI or USB/UVC outputs, each with independent resolution settings. The camera also includes a built-in halo tally light and a 2.93″ E-Ink display for enhanced functionality, while PoE (Power over Ethernet) provides both power and data transmission through a single cable, reducing setup time and minimizing cable clutter.

X1 PTZ Camera Integrated NDI | HX Decoder

An integrated NDI|HX decoder enables confidence monitoring, return feeds, and teleprompter capabilities, streamlining connections into a single cable for simpler equipment management.

X1 Camera Supports AI Tracking for Smooth Framing

AI tracking technology follows subjects intelligently in real-time, making it ideal for live events, hybrid environments, and dynamic action capture, ensuring your subjects are well-framed at all times.

X1 PTZ Camera includes Wi-Fi Connectivity Function

Built-in Wi-Fi allows wireless camera positioning, perfect for areas where cables are difficult to install, integrating effortlessly into any setting.

NDI|HX2 & NDI|HX3 Compatibility

Experience optimized network performance and image quality with NDI|HX2 and NDI|HX3 support, offering reduced network load and superior video clarity.

Halo Tally Light System

The camera’s halo tally light system, with a bright, easily visible border and customizable illuminated numbers, helps your cast and crew maintain focus, enhancing audience engagement and production quality.

Color Matrix

Dialing in your camera colors just got leveled up. X1 Ultra has a full-color matrix with individual saturation control over Red, Green, Blue, Cyan, Yellow, and Magenta, all with 64 levels of control.

NDI PTZ Control for iPad and iPhone

Take full control of your BirdDog camera, all from a super-easy-to-use iPad/iPhone app. Pan, Tilt, Zoom, save and recall pre-set PTZ positions, preview your cameras in full screen, and access all the color matrix tools and settings for your BirdDog camera.

Advanced features in BirdUI

BirdUI gives complete access to every function of your X1, all within a beautiful and intuitive interface. As a browser-based application, it can be accessed from anywhere on the same network as the X1. BirdUI adds features including a dashboard for monitoring the camera and light/dark modes to suit your production environment.

To view more BirdDog Products

View more NDI cameras

Related Products:

Other Site:

BirdDog X1 20x Zoom HD PTZ Camera

Specifications
Click to rate this post!
[Total: 1 Average: 5]

IMAGING:

  • Image Sensor: Sony 1/2.8” CMOS – FULL HD
  • Lens: f=5.5mm – 110mm
  • Optical Zoom: 20x
  • Video Format: 1080p @ 60/59.94/50/30/29.97/25fps, 720p @ 60/50/30/25fps
  • Horizontal angle of view: 55.8° (W) – 3.2° (T)
  • Vertical angle of view: 32.2° (W) – 1.8° (T)
  • Diagonal angle of view: 61° (W) – 3.64° (T)
  • Aperture: F1.6 ~ 3.5
  • Focus: Auto, Manual
  • Exposure: Auto, Shutter Priority, Iris Priority, Manual
  • Backlight Compensation: Yes
  • Digital Noise Reduction: 2D and 3D Noise Reduction
  • SNRA16: >50dB
  • Effective Pixels: 2.07 MP

MECHANICAL:

  • Pan/Tilt Rotation: ±175°, -90° ~ +90°
  • Pan Control Speed: 0.1-80°/sec
  • Tilt Control Speed: 0.1-60°/sec
  • Preset Number: 255 presets

I/O INTERFACE:

  • Video Output Interfaces: HDMI, USB-C, UVC 1.1, Network
  • Video Compression Formats: H.264, H.265
  • Network Interfaces: 100M adaptive Ethernet port; POE IEEE 802.3af, Wi-Fi IEEE 802.11ac
  • Encoder Network Protocols: NDI-HX2, NDI-HX3, RTSP, RTMP
  • HDMI Decoder Network Protocols: NDI-HX2, NDI-HX3
  • Control Interfaces: 10M/100M Ethernet, Wi-Fi IEEE 802.11ac, RS232 (input & output), RS485, TYPE-C (UVC1.1)
  • Control Protocols: VISCA Baud Rate: 38400/9600/4800/2400, VISCA-IP, NDI

GENERAL:

  • Input Voltage: DC 12V, POE IEEE 802.3af
  • Input Current: 2.0A (Max)
  • Power Consumption: 13W (Max)
  • Working Temperature: -10ºC ~ +40ºC
  • Working Humidity: 20% ~ 80%
  • Dimension (W*H*D): 171.6*192.6*171.6mm/ 260*217*197mm (before / after packing)
  • Net and Gross Weight: 1.35kg/2.05kg (Net/Gross weight)
