Blackmagic ATEM Mini Multi Camera Live Production Switcher

SKU: SWATEMMINI Category:

This model has been discontinued

Description
Click to rate this post!
[Total: 4 Average: 5]

Blackmagic ATEM Mini Low-cost Multi-Camera Live Production Switcher
This model has been replaced by Atem Mini Pro

Blackmagic ATEM Mini

Gaming streamers and video content creators used to find it hard to find a device that lets them stream their content while having their faces displayed simultaneously. In the early years of video streaming platforms like YouTube, content creators had limited options for their content due to hardware limitations. but when live production switchers like the Blackmagic ATEM Mini came along, the game was drastically changed.

With the ability to accommodate 4 sources simultaneously, the ATEM Mini allows users to mix and match different sources. Video makers can use this live production switcher to capture scenes from different angles, and gamers can utilize 2 out of 4 HDMI inputs for the camera and the game console, respectively.

Design

The Blackmagic ATEM Mini has an interface that is easy to understand and operate. If ever you get confused about what button does what, you can always consult your handbook for the details. The rubber buttons are a nice touch, as they don’t feel as stiff as plastic ones, and they light up when the corresponding buttons are pressed.

Looking at the back of the live production switcher, you will see 4 HDMI input slots, 1 HDMI output slot, an ethernet port, and a USB-C output. You can also find two mic inputs on the back panel.
All of these features are packed within a compact and sleek frame that allows you to carry your live production switcher anywhere without having to worry about encumbrance. Source

Performance

The Blackmagic ATEM Mini has all the features you have come to expect from a live production switcher and then some. With various effects like fades, cut, and mix at your disposal, your videos will have a unique feel to them. This device also has a maximum resolution of 1920×1080, providing you with crisp and clear 2k quality. A picture-in-picture mode is also present, making it possible for video game streamers to broadcast what they’re playing while their faces are on full display as well.

Extra Features

The Blackmagic ATEM Mini also comes with extra features that make post-production easier for you. In most cases, post-production methods like video and audio editing, including video effects, are necessary to add that extra flair to your projects, but all of those things can be accomplished by the ATEM Mini. More than just a live production switcher, the ATEM Mini accomplishes different tasks on its own. Here are the extra features that you will get when you purchase the Blackmagic ATEM Mini:

Audio Mixer

With the built-in audio mixer, you can customize the audio quality of your projects. Not satisfied with the bass or the treble of the speakers?
You can adjust those levels manually and get a sound that is uniquely yours.

Downstream Keyer

Some videos require logos and graphics for added flair. With the ATEM Mini, you can add these things to help improve your videos and give them that extra pop. By offering you an extra layer where you can put your graphics on, downstream keyers don’t disrupt the actual video. This feature can be fully utilized within the ATEM Mini.

Transitions

Various transitions are at your disposal with this live production switcher. Easily transition from one camera to the next, or add excellent graphics and effects like mix, dip, wipe, and cut in between, giving you amazing effects to add to your live stream or presentation.

Applications

Live streaming is one of the fastest-growing industries today, with live streamers like Ninja, xQc, and Tfue having a massive following and equally massive revenue as well. For streamers, having a picture-in-picture function is essential since viewers like to watch the gameplay or the video being presented alongside seeing the streamers’ reactions. The Blackmagic ATEM Mini allows users to do just that. With its crisp picture-in-picture feature, you too can stream like a pro. Live production switchers like the ATEM Mini also excel at giving ordinary presentations a professional look. With the ability to switch between four cameras with just a button press, you can offer different camera angles to the viewers.

Perhaps you’re hosting a video podcast? You can also use the picture-in-picture feature with the switcher to display your guest’s camera, saving you from having to edit these switches in post-production. With a plethora of effects at your disposal, every stream can be a unique experience.
The audio mixer feature is also an excellent addition, as it gives you complete control over the audio quality. Most broadcasts have a muffled sound, and that problem can be quickly fixed with just a few adjustments on the audio mixer.

Conclusion

Compact, packed with tons of features, and able to handle multiple functions, the Blackmagic ATEM Mini is an essential part of any streamer’s tools. If you’re looking for a device that will significantly improve your efficiency while working on your presentations or live streams, look no further than the Blackmagic ATEM Mini.

ATEM Mini Family product

ATEM Mini Pro Multicamera Live Production Switcher

ATEM Mini Pro ISO Live Production Switcher

ATEM Mini Extreme Live Production Switcher

ATEM Mini Extreme ISO Live Production Switcher

ATEM Streaming Bridge Switcher and Converter

Other Reading Material

Affordable Multi-camera Live Production Switcher

ATEM Mini: Clear and Easy Introduction (Pro to Extreme Quick Review)

Other Website

Blackmagic ATEM Mini

Modified Steven 27/2/23

Specifications
Click to rate this post!
[Total: 4 Average: 5]
Connections
Total Video Inputs 4
Total Outputs 2
Total Aux Outputs 1
SDI Rates 1.5G, 3G.
Total Audio Inputs 2 x 3.5mm stereo mini jack.
Total Audio Outputs None, embedded audio only.
Timecode Connection None
HDMI Video Inputs 4 x HDMI type A, 10-bit HD switchable.
2-channel embedded audio.
Video Input Re-Sync On all 4 HDMI inputs.
Frame rate and format convertors On all 4 HDMI inputs.
HDMI Program Outputs 1
Computer Outputs 1 x USB Type-C 3.1 Gen 1.
Standards
HD Video Input Standards 720p50, 720p59.94, 720p60, 1080p23.98, 1080p24, 1080p25, 1080p29.97, 1080p30, 1080p50, 1080p59.94, 1080p60, 1080i50, 1080i59.94, 1080i60
HD Video Output Standards 1080p23.98, 1080p24, 1080p25, 1080p29.97, 1080p30, 1080p50, 1080p59.94, 1080p60
Ultra HD Video Standards None
Video Sampling 4:2:2 YUV
Color Precision 10-bit
Color Space REC 709
HDMI Input Resolutions from?Computers 1280 x 720p 50Hz, 59.94Hz and 60Hz
1920 x 1080p 23.98, 24, 25, 29.97,30, 50, 59.94 and 60Hz
1920 x1080i 50 and 59.94Hz?60Hz
Colorspace Conversion Hardware-based real-time.
Audio Mixer 6 input x 2 channel mixers.
Selectable On/Off/Audio-Follow-Video per channel plus separate gain control per channel.
Level and Peak Metering. Plus new Fairlight audio enhancements: Compressor, Gate, Limiter, 6 bands of parametric EQ. Master gain control.
Product Specifics
Upstream Keyers 1
Downstream Keyers 1
Advanced Chroma Keyers 1
Linear/Luma Keyers 2
Transition Keyer DVE only
Total Number of?Layers 4
Pattern Generators 1
Color Generators 2
DVE with Borders and Drop Shadow 1
Interface Minimum monitor resolution of 1366 x 768
Media Player
Media Players 1
Channels Fill and key for each Media Player.
Media Pool Still Image Capacity 20 with fill and key.
Media Pool Still ImageFormat PNG, TGA, BMP, GIF, JPEG, and, TIFF.
Control
Control Panel Built-in control panel. Software control panel included. Supports optional hardware panel.
Control Panel Connection Ethernet supports 10/100 BaseT. Allows direct connection between panel and chassis, or via network. Also used for updating the software. ATEM Mini supports direct USB-C connection.
Control Panel Compatibility Includes ATEM Software Control Panel. Also compatible. with ATEM 1 M/E Advanced Panel and ATEM 2M/E Broadcast Panel.
Control Panel Included ATEM Software Control Panel is included free for Mac 10.13 High Sierra, Mac 10.14 Mojave or later, and Windows 10.
Software
Software Updates Using USB or Ethernet connection directly connected to Mac OS X or Windows computers. Includes ATEM Switcher Utility.
Configuration Set via ATEM Software Control Panel, excluding ATEM chassis IP address which is set via the ATEM Switcher Utility connected via USB to chassis.
Power Requirements
Power Supply 1 x External 12V power supply.
Power Usage 18W
Environmental Specifications
Operating Temperature 5° C to 40°C (41° – 104°F)
Storage Temperature -10° to 60°C (14° to 140°F)
Relative Humidity 0% to 90% non-condensing
In The Box
Click to rate this post!
[Total: 4 Average: 5]
  • ATEM Mini
  • External 12V power supply with locking connector and international socket adapters
