| Connections |
| HDMI 2.0b Video Inputs |
4 |
| HDMI Audio Inputs |
8 Channels embedded in SD/HD/UHD/4K. |
| Computer Interface |
PCI Express 8 lane generation 3, compatible with 8 and 16-lane PCI Express slots. |
| Supported Codecs |
AVC-Intra, AVCHD, Canon XF MPEG2, Digital SLR, DV-NTSC, DV-PAL, DVCPRO50, DVCPROHD, DPX, HDV, XDCAM EX, XDCAM HD, XDCAM HD422, DNxHR, DNxHD, Apple ProRes 4444, Apple ProRes 422 HQ, Apple ProRes 422, Apple ProRes LT, Apple ProRes 422 Proxy, Uncompressed 8-bit 4:2:2, Uncompressed 10‑bit 4:2:2. |
| Software |
| Software Included |
Media Express, Disk Speed Test, Blackmagic Desktop Video Utility, and Blackmagic driver on Mac OS and Windows. Media Express, Blackmagic Desktop Video Utility, and Blackmagic Driver on Linux. |
| Internal Software Upgrade |
Firmware built into software driver. Loaded at system start or via updater software.
|
| Physical Installation |
PCI Express 8 lane generation 3, compatible with 8, 16 lane PCI Express slots on Mac OS, Windows, and Linux. Please check the Support pages to see the full system requirements. |
| Software Applications |
Wirecast, vMix, OBS |
| Other supported applications include |
Cinegy Capture Pro, DevTek EasyMediaSuite, Glookast Capturer, Livestream Producer, Metus Ingest, Softron MovieRecorder, ToolsOnAir just:in, Burst Video WebClip2Go & [REC]Marker, Zoom.
These are third-party applications and support may vary, check with your software vendor. |
| Video Standards |
| SD Video Standards |
525i59.94 NTSC, 625i50 PAL |
| HD Video Standards |
720p50, 720p59.94, 720p60
1080p23.98, 1080p24, 1080p25, 1080p29.97, 1080p30, 1080p50, 1080p59.94, 1080p60
1080i50, 1080i59.94, 1080i60 |
| Ultra HD Video Standards |
2160p23.98, 2160p24, 2160p25, 2160p29.97, 2160p30, 2160p50, 2160p59.94, 2160p60 |
| 4K Video Standards |
4Kp23.98 DCI, 4Kp24 DCI, 4Kp25 DCI, 4Kp29.97 DCI, 4Kp30 DCI, 4Kp50 DCI, 4Kp59.94 DCI, 4Kp60 DCI |
| Digital Video Interface (DVI) Standards |
640x480p60, 800x600p50, 800x600p60, 1440x900p50 1440x900p60, 1440x1080p50 1440x1080p60, 1600x1200p50, 1600x1200p60, 1920x1200p50, 1920x1200p60, 1920x1440p50, 1920x1440p60, 2560x1440p50, 2560x1440p60, 2560x1600p50, 2560x1600p60 |
| Audio Sampling |
Television standard sample rate of 48 kHz and 24 bit. |
| HDMI Colour Precision |
8, 10, 12-bit RGB 4:4:4 in all modes up to 4Kp30 DCI and 8, 10-bit YUV 4:2:2 in all modes. 8-bit YUV 4:2:0 in Ultra HD and 4K DCI 50p and 60p. 8‑bit RGB 4:4:4 in all DVI modes. |
| Color Space |
REC 601, REC 709, REC 2020 |
| HDMI Video Sampling |
4:4:4, 4:2:2 and 4:2:0 |
| HDMI Configuration |
HDMI 2.0b supports Deep Color and HDR. |
| Multiple Rate Support |
HDMI inputs are switchable between SD, HD, Ultra HD, 4K DCI, and DVI modes. |
| Copy Protection |
HDMI input is unable to capture from copy-protected HDMI sources. Always confirm copyright ownership before capturing or distributing content. |
| Operating Systems |
Mac OS 10.13 High Sierra, Mac OS 10.14 Mojave or later, Windows 7, 8.1, and 10, all 64-bit. Linux |
| Power Requirements |
| Power Consumption |
23 W |
| Environmental Specifications |
| Operating temperature |
5° to 40° C (41° to 104° F) |
| Storage temperature |
-20° to 45° C (-4° to 113° F) |
| Relative Humidity |
0% to 90% non-condensing |
| Warranty |
3-Year Limited Manufacturer’s Warranty.
|
