Canon EOS C200 EF Cinema Camera with 4K UHD and Full HD Recording

In stock

• Super 35mm Format 8.85-megapixel CMOS Sensor
• Compatible with both DCI 4K/UHD 4K
• Cinema RAW Light (No external recorder required for recording)
• Dual Pixel CMOS AF & Dual Pixel Focus Guide
• Full HD 120P/100P
• Expandable to ISO 100, ISO 102400
• Wi-Fi

SKU: EOS C200 Categories: ,

Encompasses both mobility and the expressive power of 4K
The 8.85 effective megapixels of the EOS C200’s 4K Super 35mm, large-format CMOS sensor weaves ultra high-definition and richly textured imagery, aided by the newly-developed Dual DIGIC DV 6 image processing platform. The camera supports a new RAW format, Cinema RAW Light, which can record DCI 4K 60P/50P RAW images to a CFast 2.0 (VPG130) card without the need for an external recorder.

4K Cinema RAW Light files contain abundant information, which not only enables format conversion with less image degradation but is also ideal for HDR recording. Meanwhile, 4K UHD 60P/50P movies can be recorded in the versatile MP4 format to SD cards. Dual Pixel CMOS AF, which is supported via touchscreen operation, enables easy and convenient pinpoint focusing.

A compatible sub-camera for the EOS C700 and C300 Mark II with its support for Canon Log and Canon Log-3, the EOS C200’s lightweight, compact body also makes it suitable for use on the field, whether for on-scene reporting or for documentary shoots.

Record in DCI 4K & 4K UHD – no external recorder required
Equipped with two sets of Canon’s latest image processing platform, DIGIC DV 6, the EOS C200 supports recording 60P/50P footage in not just DCI 4K, but also 4K UHD format, without the need for an external recorder. DCI 4K footage can be directly recorded onto a CFast 2.0 card using the new Cinema RAW Light format, which results in data sizes that are 1/3 to 1/5 of the size of conventional Cinema RAW files. As this format allows colour grading not depending on specific output devices or the latest trends, it is a powerful tool for creating HDR footage. UHD footage can be recorded onto an SD card using the versatile MP4 format. Two SD card slots provide brilliant support for recording over long durations. SDI output features support for ACESproxy version 1.0, where, by using a compatible display device, users can check images during colour grading and even whilst shooting, improving workflow efficiency.

Beautiful 4K footage with the Super 35mm CMOS format sensor
Equipped with the same 8.85-megapixel Super 35mm format CMOS sensor as the flagship model EOS C700, the EOS C200 provides 4K footage with rich colour gradations and high-definition image quality. ISO speed can go as low as ISO 100 (expanded), which, when used together with the built-in ND filter, makes it possible to achieve the bokeh quality unique to a large-format sensor even in daylight. Maximum ISO speed is as high as ISO 102400 and expandable to Gain 54dB, broadening your range of shooting possibilities to include even on-location shots at night where lighting conditions are unfavorable. The depth of 4K expression is also effectively utilized even in 2K/Full HD output, where Over Sampling HD Processing carries non-additive resizing on the 4K data. This process also suppresses moire and reduces graininess from noise, making pristine images free of scaling artifacts a possibility.

Dual Pixel CMOS AF for touch panel AF operation
Autofocusing is carried out with the Canon-developed Dual Pixel CMOS AF system, which realizes fast, seamless AF and covers approximately 80% (vertically and horizontally) of the screen. Face Detection AF and Continuous AF are also possible. In 4K large sensor based image acquisition where ensuring tack-sharp focus may not be a simple task for a single-operator, the support for touch panel AF operation is a powerful benefit, enabling easier single-operator focusing. Selected EF Cinema Servo lenses are supported, and so are the wide selection of EF range lenses. The camera also features a menu for tuning AF speed and subject tracking characteristics, as well as a new “AF-Boosted MF” mode which ensures a reduced chance of inadvertent “focus-hunting” movements. In line with the needs of filmmakers, the fine-tuning of focusing operations is also possible. The camera supports the Browser Remote function, which allows remote camera settings control with a web browser enabled tablet via a Wi-Fi connection, enabling it to carry out precise focusing through touch operation when using a crane or drone.

Image Sensing Device
Sensor CMOS Sensor (single-panel) equivalent to Super 35mm
Total Pixels Approx. 9.84 megapixels (4206 x 2340)
Number of Effective Pixels Approx. 8.85 megapixels (4096 x 2160):
When 4096 x 2160 or 2048 x 1080 is selected as the resolution

Approx. 8.29 megapixels (3840 x 2160):
When 3840 x 2160 or 1920 x 1080 is selected as the resolution

Filter RGB primary color filter (Bayer array)
Lens Mount Canon EF mount
Exposure Modes (1) Manual exposure based on shutter setting, iris setting, ISO/gain setting, and ND filter setting
(2) Push auto iris control, auto iris control (light metering system selection/AE shift possible)
Shutter Setting Speed, Angle, Clear Scan, Slow, or Off mode selected
Either 1/3 or 1/4 steps selected as speed increment

(1) Manual setting in 1/2-step increments, 1/3-step increments or fine possible
(2) Push auto IRIS control*
(3) Auto IRIS control*

* Lenses that support auto IRIS:

ISO Speed Setting 1 step, 1/3 step settings
[100* – 160 – 25600 – 102400*]
*When the sensitivity is expanded
Gain Setting Normal [-6dB* – -2dB – 42dB – 54dB*]
Fine: Setting in 0.5 dB step increments possible
*When the sensitivity is expanded
ND Filter 5 density settings (2, 4, 6, 8*, 10* stops)
*When expansion is selected
Motorized drive
Focus Control
Dual Pixel CMOS AF Supported
Manual Focus, One-Shot AF, Continuous AF, AF-Boosted MF, Face Detection AF (only lenses that support AF functions can be used in any of these modes), Focus Guide
Built-in Viewfinder 0.46” (1.18 cm on the diagonal), color wide-screen organic EL display
Approx. 1,770,000 dots (854 x RGB x 480), 100% field of view ratio
White Balance AWB, Kelvin setting (setting range: 2000K to 15000K/-20CC to +20CC), Daylight, Tungsten, Set A, Set B)
Frame Rate (1) 59.94 Hz mode (59.94P/29.97P/23.98P)
(2) 50.00 Hz mode (50.00P/25.00P)
(3) 24.00 Hz mode (24.00P)
Dynamic Range Canon Log 3: 1600% (ISO 800 or above)
Canon Log/Wide DR: 800% (ISO 400 or above)
Video Formats
RAW Video:
Codec: Cinema RAW Light
Resolution: 4096 x 2160
Bit Depth: 10 bit (59.94P/50.00P), 12 bit (29.97P/23.98P/25.00P/24.00P)
Bit Rate: 1 Gbps

Linear PCM: 16-bit / 48 kHz / 4 channels

MP4 Video:
Codec: MPEG-4 AVC/H.264
Resolution: 3840×2160 / 1920×1080
Bit Rate: 150 Mbps (3840×2160), 35 Mbps (1920×1080)
Color Sampling: YCC420 8 bit

MPEG-4 AAC-LC (16-bit / 48 kHz / 2 channels)
Linear PCM (16-bit / 48 kHz / 4 channels)

MP4 (Proxy) Video:
Resolution: 2048 x 1080
Bit Rate: 35 Mbps
Color Sampling: YCC420 8 bit

MPEG-4 AAC-LC (16-bit / 48 kHz / 2 channels)
Linear PCM (16-bit / 48 kHz / 4 channels)

Recording Media
Recording Media (1) CFast™ card (1 slot) Supports VPG130: RAW movies
(2) SD card (2 slots): Recording of MP4 movies, photos (JPEG), custom pictures, menus and other data possible
Time Code Drop frame* or non-drop frame
Rec run, free run, regeneration
*In 59.94P/29.97P mode only
Rec Mode (MP4 Recording) Slow motion recording, pre-recording, frame recording, interval recording
Other Recording Functions (MP4 Recording) Relay recording, double slot recording
Others Custom picture setting, black balance adjustments, color bars, peaking display, zebra display, My Menu setting, fan, waveform monitor display, assignable buttons (1-17), key lock, marker display, enlarged display, custom display, peripheral illumination correction, GPS support (GP-E2), monaural microphone, and other functions
Input only:
REMOTE terminal, MIC jack, INPUT terminals (2 sets)

Output only:
SDI terminal, HDMI OUT terminal, headphones jack, USB terminal, VIDEO terminal

Input/Output Control:
Ethernet terminal

Power Supply
Power Supply 14.4 V DC (battery pack), 16.7 V DC (DC-IN)
Image Processing Platform
Image Processing Platform Dual DIGIC DV 6
Weight and Dimensions
Dimensions (W x H x D) Approx. 5.7 x 6.0 x 7.0 in. (144 x 153 x 179mm)
Approx. 7.0 x 6.0 x 8.0 in. (178 x 153 x 204mm) [With camera grip attached]
Approx. 13.2 x 10.8 x 10.8 in. (335 x 275 x 275mm)
[With camera grip + LCD Monitor LM-V1 + LCD Attachment Unit LA-V1 + Handle Unit HDU-2 + mic holder
Weight Approx. 3.2 lb. (1430g)
