Description

An essential link to connect all your equipment for your live production

Datavideo HBT-50 supplies power, video signal, and camera control for up to 4 devices up to 100 meters distance. It simultaneously outputs HDMI, SDI, RS-422, and IP control signals.

Add HDBaseT to your SDI Workflow seamlessly

Datavideo HBT-50 can power the PTZ video cameras via PoE, transmit signals over a single ethernet cable to and from the camera, and can be used to remotely control various camera parameters such as iris, presets and etc. Most importantly, it can output an SDI signal to your switcher.

Integrate camera control, switcher, and recorder operations

HBT-50 simultaneously transmits SDI (up to 1080p60) and HDMI (up to 1080p60) as well as camera control. With the HBT-50, the system can be an integrated camera controller, video switcher, and ISO recorder.

Simultaneously outputs HDMI, SDI

HBT-50 provides outputs HDMI and SDI simultaneously. It is great for us on long-distance camera video transmitting to the switcher, or ISO recorder. There is no need to prepare 4 additional HDBaseT receivers, HBT-50 will get the work done for it.

Perfect solution for your broadcast SDI workflow

Remote control of camera functions via RS-422 or DVIP with SDI video transmission (up to 1080p50/60) and HDMI video transmission (up to 1080p50/60) up to 4 cameras simultaneously up to 100m.

Specifications

General Specifications
Model Number	HBT-50
Video/Audio Input	HDBaseT x 4 (with PoE and IEEE 802.3at)
Video/Audio Output	HDMI x 4 (up to 1080p50/59.94/60) SDI x 4 (up to 1080p50/59.94/60)
Supported Video Format	1080p: 60/59.94/50/30/29.97/25/24/23.98 1080i: 60/59.94/50, 720p: 60/59.94/50
Video Process	–
Video bandwidth	–
DVIP	RJ-45 x1(input)
RS-422/ RS-232	RJ-45 x 4 (RS-232/RS-422)
Power	AC In
PoE Output	65W per channel
HDBaseT Distance	1080p50/59.94/60 up to 100m by CAT.6 cables
HDMI compliance	–
HDCP compliance	–
Audio support	–
Dimension (LxWxH)	440 x 286 x 49mm
Weight	4.2 kg
Operating Temp. Range	0~40 °C

In The Box

1 x HBT-50 main unit
1 x AC Cord
