JVC GY-HM250HW Live Stream Video Camera

Weight	2 kg

Description
Features
Specifications
Delivery Info
Reviews (0)

JVC GY-HM250HW Live Stream Video Camera w/On-board Titling

The JVC GY-HM250HW features JVC’s latest IP communications engine letting you stream your church events to a decoder at a cable head-end, or directly to the internet through your favorite content delivery network such as YouTube, USTREAM, Sunday Streams, Worchip Channels or JVC’s own VIDEOCLOUD.

Just press one button on the camera and you’re streaming to the world! Live streaming is possible in HD or lower resolutions, depending on available bandwidth. Remote control and monitoring of vital camera and lens functions is possible from a tablet, smartphone, or computer. And while streaming, the camera continues to function as a high quality, full HD camcorder giving you a pristine copy of the service with or without graphic overlay.

Graphic & Titling Solutions for a Single Camera Operator

Designed for enhanced single-camera production, the JVC GY-HM250U offers lower-third and full-screen titling solutions for recorded or streamed HD video output without an external CG or production switcher. Lower-third graphic overlays are generated and controlled using a browser-equipped device such as a tablet or smartphone.

JVC’s software utility lets you upload logos or icons to be displayed in the lower-third of the recorded video. The camera also comes with several pre-installed color schemes and the ability to add your own text bar designs also exists. The new GY-HM250HW is perfect for streaming Sunday services, weddings, memorials, family and church events, or literally any occasion you want to share live!

The JVC GY-HM250HW produces a graphic overlay on recorded or streamed video output with graphic icons for several holy events. The overlay is produced for both the streamed and recorded video simultaneously. No external character generator is necessary.

Add up to 50 full screen custom graphics (PNG or JPG format) from an SD card and store them in the camera for live streaming or recording in the HD mode. Graphics may be advanced manually or presented as a looping slideshow with timing 1-99 seconds per slide. This new feature allows users to create opening and closing graphics, scripture passages, hymn lyrics and much more.

Graphics may be produced with PowerPoint or any photo editing software and saved as a series of image files. PNG graphics provide the most flexibility for creating overlays because they allow you to create transparent backgrounds. Full-screen graphics are saved at 960×540 and upscaled to 1920×1080. Stored graphics may be shown independently or concurrently with the lower third graphics generated in the camera.

Integrated 12x Ultra HD Lens, 1/2.3-inch CMOS Sensor

The JVC GY-HM250HW was built to deliver stunning, true to life video. The ultra high quality imagery begins with a precision 12x F1.2-3.5 optical zoom lens (35mm equivalent: 29.6-355mm). JVC’s 4K CMOS sensor with 12.4M pixels delivers high sensitivity and excellent performance over a wide range of lighting conditions.

Details are crisp and accurate throughout the entire image plane. When shooting in the HD mode, Dynamic Zoom combines optical zoom and pixel mapping to create seamless and lossless 24x zoom.

Dual SDHC/SDXC Card Slots

The GY-HM250HW can create hours of pristine recordings to affordable nonproprietary SDHC/SDXC media in a variety of image formats including 4K Ultra HD, Full HD with 4:2:2 sampling, and SD and web friendly proxy formats. Dual SDHC/SDXC card slots make it truly versatile, offering such benefits as simultaneous recording and relay recording. In relay recording mode, you can shoot the event continuously over multiple cards—when one card is full, the camcorder switches automatically and seamlessly to the other card—perfect for longer ceremonies!

Features

Single 1/2.3-inch CMOS image sensor with 12.4m pixels
High quality integrated 12x F1.2-3.5 zoom lens (35mm equivalent: 29.6-355mm)
Graphic overlay with custom logo option
Dynamic Zoom in HD mode combines optical zoom and pixel mapping to create seamless and lossless 24x zoom
4K Ultra HD recording (150 Mbps, 24/30p) to SDXC (UHS-I Speed class3) cards
4K Ultra HD recording (70 Mbps, 24/30p) to SDXC/SDHC (Class 10) cards
4:2:2 Full HD (24-60p) recording at 50Mbps
120fps HD Slo-Mo recording
Live 4K UHD output via HDMI connector
2 position ND filter (1/4, 1/16)
HD-SDI (3G) and HDMI outputs (4K output via HDMI only)
HD-SDI and HDMI outputs can feed and trigger external recorder
2-channel XLR audio inputs with phantom power
Built-in stereo microphone
Dual SDHC/SDXC slots enable dual, backup and continuous recording
Advanced JVC streaming engine compatible with USTREAM, Zixi and Wowza Streaming Engine
IP Network Remote Control, Remote Viewing, Scorekeeping, Metadata editing, FTP clips*
3.5-inch color LCD display (920K pixel) with smart focus assist function
0.24-inch color viewfinder (1.56M pixel) with smart focus assist function
Histogram Display
Wired remote control supported
9 user button assignable functions
Includes handle unit, SSL-JVC50 7.4V battery, and an AC Adapter

Specifications

GENERAL SPECIFICATIONS
Power	DC 12V (AC adapter), DC 7.4V (Battery)
Power Consumption	Approx. Approx. 7.9W （with VF in 4K REC mode, default setting)
Weight	Approx. 3.53 lb (1.6kg) (including battery)
Dimensions	149(W) x 191(H) x 307(D)mm
Operation temperature	0℃ to 40℃　(32°F to 104°F)
Storage temperature	-20℃ to 50℃ ( 14°F to 122°F)
Operating humidity	30% to 80%
Storage humidity	under 85%
CAMERA
Image Sensor	1/2.3-inch Back Side Illuminated CMOS Total 12.4M pixels
Synchronizing	Internal synchronization
Stabilizer	Optical image stabilizer
Shutter speed	1/6～ 1/10000
Lens	F1.2 (wide) to F3.5 (tele) f=4.67mm to 56.04mm 35mm equivalent: 29.6mm to 355mm
Filter diameter	62mm
Gain	0, 3, 6, 9, 12, 15, 18,21,24 dB, Lolux(30,36 dB), AGC
ND filter	none , 1/4, 1/16
LCD display	3.5-inch 920 k pixels, 16:9
Viewfinder	0.24-inch 1.56 M pixel, 16:9
VIDEO/AUDIO RECORDING
Recording media	2x SDHC/SDXC memory card (4K:UHS-1 U3, HD:50Mbps Class10, HD:35Mbps Class6, AVCHD/SD Class4)
Video recording	Video codec: MPEG-4 AVC/H.264 (4K/HD/SD/Proxy) ,AVCHD(HD/SD) File format : MOV(H.264), MTS(AVCHD)
4K(H.264)	NTSC setting: 3840 x 2160/29.97p, 23.98p (70,150 Mbps) PAL setting: 3840 x 2160/25p (70,150Mbps) PAL setting: 3840 x 2160/25p
HD(H.264)	NTSC setting: YUV422 mode:1920 x1080/59.94p.29.97p,23.98p(50Mbps), XHQ mode: 1920×1080/59.94p,29.97p,23.98p(50Mbps) UHQ mode: 1920×1080/59.94i,29.97p, 23.98p(35Mbps) 1280×720/59.94p(35Mbps) PAL setting: XHQ mode:1920 x 1080/50p(50Mbps) XHQ mode:1920×1080/50p,50i,25p(50Mbps),1920×1080/50i,25p(35Mbps), 1280×720/50p(35Mbps)
AVCHD	NTSC setting: Progressive mode(Max 28Mbps):1920 x 1080/59.94p, HQ mode(24Mbps):1920 x 1080/59.94i, SP mode(17Mbps):1920 x1080/59.94i LP mode(9Mbps):1440 x 1080/59.94i (Web mode), EP mode(5Mbps):1440 x1080/59.94i (Web mode) PAL setting: Progressive mode(Max 28Mbps):1920 x 1080/50p, HQ mode(24Mbps):1920 x 1080/50i, SP mode(17Mbps):1920 x1080/50i LP mode(9Mbps):1440 x 1080/50i (Web mode), EP mode(5Mbps):1440 x1080/50i (Web mode)
SD(MOV/AVCHD)	NTSC setting: 720 x 480/59.94i (8 Mpbs)
Proxy(H.264)	NTSC setting: HQ mode(3Mbps):960 x 540/29.97p, 23.98p, LP mode(1.2Mbps):480 x 270/29.97p, 23.98p PAL setting: HQ mode(3Mbps):960 x 540/25p, LP mode(1.2Mbps):480 x 270/25p
Audio recording	LPCM 2ch, 48kHz/16-bit(4k/HD/SD MOV)), AC3 2ch(AVCHD), μlow 2ch(Proxy)
LIVE VIDEO STREAMING
Protocol	RTMP, MPEG2-TS/UDP, MPEG2-TS/TCP, RTSP/RTP, ZIXI
Bitrate	0.2 – 12 Mbps
Resolution	1920×1080, 1280×720, 720×480, 480×270
INTERFACE
Video output	AV output (φ3.5mm mini jack x1) SDI output (BNC x1) HDMI output x1
Audio input	XLR x2 (MIC,+48V/LINE), φ3.5mm mini jack x1
Audio output	AV output (φ3.5mm mini jack x1)
Headphone	φ3.5mm mini jack x1
Remote	φ2.5mm mini jack x1
USB	HOST x1(Network Connection) , DEVICEx1(Mass storage) Supported devices: Verizon, AT&T 4G LTE modems, Wi-Fi and LAN adapters
Network Function	Live Video Streaming, FTP, Remote Control
INCLUDED ACCESSORIES
Handle unit, Battery(SSL-JVC50) x1, AC Adapter x1
