Panasonic AG-CX10 4K 60p Camcorder with P2 MXF and NDI | HX
Smallest, Lightest 4K 60p Camcorder
Industry’s Smallest and Lightest 4K 60p Director’s Camcorder
While excelling in mobility and portability, the Panasonic AG-CX10 4K compact body considers the weight balance of the advanced functions when shooting.
Panasonic AG-CX10 4K Wide 25mm* and Optical 24x Zoom Lens
The Panasonic AG-CX10 4K lens covers the range from 25mm wide-angle to 600mm tele with a 24x zoom. i.ZOOM achieves 32x zoom with 4K resolution, and 48x zoom with FHD.
* 35mm camera equivalent.
4K High-Precision AF
Panasonic AG-CX10 4K Face Detection precisely captures subjects on-site free from out of focus problems and insufficient exposure. Also, by adding color recognition, tracking subjects is improved, without interruption, when the face moves to either side.
HYBRID O.I.S.
In both UHD/FHD modes, in addition to Optical Image Stabilization, Electronic Image Stabilization detects and corrects handshake in the 5-axis direction. The Ball O.I.S. System reduces friction in the drive section, especially improving the correction of small-amplitude blurring.
Heat-Dispersing Design
Panasonic AG-CX10 4K a new ultrathin fan disperses heat in a camcorder with integrated lens and 4K 60p recording. It is the industry’s smallest and lightest unit with low power consumption.
Versatile Recording Modes
Panasonic AG-CX10 4K Supports a high bit rate of 200 Mbps for 59.94p/50p video recording with HEVC (LongGOP/10 bit 4:2:0/MOV) codec, and 120/100fps* Super Slow-motion with 10-bit recording in FHD.
* 59.94Hz: 120fps, 50Hz: 100fps
Panasonic AG-CX10 4K 4:2:2 10-bit Internal Recording
Records a 4:2:2 10-bit color profile of up to LongGOP UHD 29.97p/25p (150 Mbps), or FHD 59.94p/50p (100 Mbps) with SD cards. Outputs 10-bit UHD 59.94p/50p images via HDMI.
P2 MXF File Formats Supported
Along with MOV, MP4, and AVCHD file formats, the advanced editing system for broadcasters, P2 MXF, is supported* with AVC-Intra/AVC-LongG codecs.
* AVC-Intra100/50 codec support is planned for the future. microP2 cards are required for acquisition in all P2 formats.
Full-HD Live Streaming
RTSP/RTP/RTMP/RTMPS-compatible HD streaming enables direct connection and distribution of relays for concerts, sports events, and news flashes to Facebook, YouTube, etc.
Wireless Control from a Tablet or Smartphone
Panasonic AG-CX10 4K Wi-Fi module is built-in, so Wi-Fi connection of only the body is possible. Using a tablet or smartphone app HC ROP, wireless camera settings, and lens control are also possible.
Easy IP Connection: NDI|HX Capable
Transmits data and camera control via IP connection, without a converter. Linking the AV-HLC100 and HN/UN Series enables a live streaming system.
* Recording, streaming and 4K output are not available when using NDI|HX mode.
Features
- Smallest and Lightest 4K 60p Director’s Camcorder
- Wide 25mm* and Optical 24x Zoom Lens
- 4K High-Precision AF
- HYBRID O.I.S.
- Heat-Dispersing Design
- Versatile Recording Modes
- 4:2:2 10-bit Internal Recording
- P2 MXF File Formats Supported
- Full-HD Live Streaming
- Wireless Control from a Tablet or Smartphone
- Easy IP Connection: NDI|HX Capable
Specifications
| SENSOR SECTION | |
|---|---|
| Image Sensor | 1/2.5-type (inch) MOS Sensor |
| Effective Pixels | 8.29 megapixels |
| LENS SECTION | |
| F Value | F1.8-4.0 |
| Optical Zoom | 24x |
| Focal Length | 4.12-98.9mm |
| 35 mm Film Camera Equivalent | 25.0-600.0 mm |
| Filter Diameter | 62 mm |
| Lens Brand | Leica Dicomar Lens |
| CAMERA SECTION | |
| Minimum Illumination | 1.5 lx (F1.8, Super Gain +, 1/30) |
| Focus | Auto / Manual |
| Zoom | Intelligent Zoom OFF: 24x |
| Intelligent Zoom ON: Max. 48x (UHD 32x) | |
| Digital Zoom: 2x / 5x / 10x | |
| ND Filter | 1/4, 1/16, 1/64, OFF |
| IR Filter | Incorporates the ON/OFF control function |
| White Balance | Auto / ATW LOCK / 3200K / 5600K / VAR (2000K-15000K) / Ach Fixed / Bch Fixed |
| Shutter Speed | 59.94 Hz mode ・59.94i/59.94p: 1/60, 1/100, 1/120, 1/180, 1/250, 1/350, 1/500, 1/750, 1/1000, 1/1500,1/2000, 1/3000, 1/4000, 1/8000 sec ・29.97p: 1/30, 1/50, 1/60, 1/100, 1/120, 1/180, 1/250, 1/350, 1/500, 1/750, 1/1000, 1/1500, 1/2000, 1/3000, 1/4000, 1/8000 sec ・23.98p: 1/24, 1/48, 1/50, 1/60, 1/100, 1/120, 1/180, 1/250, 1/350, 1/500, 1/750, 1/1000, 1/1500, 1/2000, 1/3000, 1/4000, 1/8000 sec |
| 50.00 Hz mode ・50i/50p: 1/50, 1/60, 1/100, 1/125, 1/180, 1/250, 1/350, 1/500, 1/750, 1/1000, 1/1500, 1/2000, 1/3000, 1/4000, 1/8000 sec ・25p: 1/25, 1/50, 1/60, 1/100, 1/125, 1/180, 1/250, 1/350, 1/500, 1/750, 1/1000, 1/1500, 1/2000, 1/3000, 1/4000, 1/8000 sec | |
| Slow Shutter Speed | 59.94 Hz mode 59.94i/59.94p: 1/8, 1/15, 1/30 sec 29.97p: 1/8, 1/15 sec 23.98p: 1/6, 1/12 sec |
| 50.00 Hz mode 50i/50p: 1/6, 1/12, 1/25 sec 25p: 1/6, 1/12 sec | |
| Super Slow Recording Frame Rate | 59.94 Hz mode FHD 120 fps (1/2 speed at 60p, 1/4 speed at 30p, 1/5 speed at 24p) |
| 50.00 Hz mode FHD 100 fps (1/2 speed at 50p, 1/4 speed at 25p) | |
| Iris | Auto / Manual |
| Image Stabilizer | Ball O.I.S., 5-Axis HYBRID O.I.S. (UHD/FHD) |
| RECORDING SECTION | |
| Recording Media | SDHC/SDXC Memory Card, microP2 card (A series, B series) |
| Recording Format | MOV, MP4, AVCHD, P2 |
| Video Compression Method | MOV/MP4: H.264/MPEG-4 AVC High Profile, H.265/MPEG-H HEVC Main10 Profile AVCHD: H.264/MPEG-4 AVC High Profile P2: AVC-LongG 50/AVC-LongG25: MPEG-4 AVC/H.264 High Profile |
| Audio Compression Method | MOV / P2: LPCM (24bit 2ch) MP4: AAC (16bit 2ch) AVCHD: Dolby Audio (16bit 2ch) |
| System Frequency | 59.94Hz / 50.00Hz |
| Recording / Playback Mode | MOV (HEVC) [4:2:0 10bit] UHD 3840 x 2160 59.94p/50.00p HEVC 200M: Average 200 Mbps (VBR) UHD 3840 x 2160 29.97p/25.00p/23.98p HEVC 150M: Average 150 Mbps (VBR) |
| MOV [4:2:0 8bit] UHD 3840 x 2160 59.94p/50.00p 150M: Average 150 Mbps (VBR) UHD 3840 x 2160 29.97p/25.00p/23.98p 100M: Average 100 Mbps (VBR) [4:2:2 10bit] UHD 3840 x 2160 29.97p/25.00p/23.98p 150M: Average 150 Mbps (VBR) FHD 1920 x 1080 59.94p/50.00p 200M (ALL-Intra): Average 200 Mbps (VBR) FHD 1920 x 1080 29.97p/25.00p/23.98p 100M (ALL-Intra): Average 100 Mbps (VBR) FHD 1920 x 1080 59.94i/50i 100M (ALL-Intra): Average 100 Mbps (VBR) FHD 1920 x 1080 59.94p/50.00p 100M: Average 100 Mbps (VBR) FHD 1920 x 1080 29.97p/25.00p/23.98p/59.94i/50.00i 50M: Average 50 Mbps (VBR) | |
| MP4 (HEVC) [4:2:0 10bit] UHD 3840 x 2160 59.94p/50.00p HEVC 100M: Average 100 Mbps (VBR) UHD 3840 x 2160 29.97p/25.00p/23.98p HEVC 72M: Average 72 Mbps (VBR) | |
| MP4 [4:2:0 8bit] UHD 3840 x 2160 29.97p/25.00p/23.98p 72M: Average 72 Mbps (VBR) FHD 1920 x 1080 59.94p/50.00p/23.98p 50M: Average 50 Mbps (VBR) | |
| AVCHD [4:2:0 8bit] PS 1920 x 1080 59.94p/50.00p: Average 25 Mbps (VBR) PH 1920 x 1080 59.94i/50.00i/23.98p: Average 21 Mbps (VBR) HA 1920 x 1080 59.94i/50.00i: Average 17 Mbps (VBR) PM 1280 x 720 59.94p/50.00p: Average 8 Mbps (VBR) | |
| P2 [4:2:2 10bit] FHD 1920 x 1080 59.94i/50i: Average 50 Mbps (VBR) FHD 1920 x 1080 59.94p/50.00p/59.94i/50.00i: Average 50 Mbps (VBR) HD 1280 x 720 59.94p/50.00p: Average 50 Mbps (VBR) HD 1280 x 720 59.94p/50.00p: Average 25 Mbps (VBR) | |
| LIVE STREAMING | |
| Video Compression Format | H.264/MPEG-4 AVC Main Profile, High Profile |
| Video Resolution | 1920 x 1080 (FHD), 1280 x 720 (HD), 640 x 360, 320 x 180 |
| Streaming Method | Unicast, Multicast |
| Frame Rate | System frequency = 59.94 Hz: 30 fps, 60 fps System frequency = 50.00 Hz: 25 fps, 50 fps |
| Bit Rate | 24 Mbps, 20 Mbps, 16 Mbps, 14 Mbps, 8 Mbps, 6 Mbps, 4 Mbps, 3 Mbps, 2 Mbps, 1.5 Mbps, 1 Mbps, 0.7 Mbps, 0.5 Mbps |
| Audio Compression Format | AAC-LC, 48 kHz/16 bit, 2ch |
| Network Protocol | RTSP/RTP/RTMP/RTMPS |
| STILL IMAGE SECTION | |
| Recording Format | JPEG (DCF/Exif2.2) |
| Recording Image Size* | Video Playback Mode: 3840 x 2160 (16:9), 1920 x 1080 (16:9), 1280 x 720 (16:9) |
| GENERAL SECTION | |
| Power Supply | 7.28V (Battery) / 12V (AC Adaptor) |
| Power Consumption | 15.5W (LCD Monitor) |
| Dimensions (W x H x D) | Approx. 129 x 159 x 257 mm (5.08 x 6.26 x 10.1 inch) |
| Weight | Body: approx. 0.9kg (1.98 lb) (body only, excluding handle, lens hood, battery, and accessories) Shooting: approx. 1.5kg (3.31 lb) (including handle, lens hood, battery, and eyecup) |
| LCD Monitor | 8.88 cm (3.5-inch) Wide LCD monitor (About 2,760,000 dots) (For Europe) 3.5-inch Wide LCD monitor (About 2,760,000 dots) (For North America / Asia) |
| Viewfinder | 0.61 cm (0.24-inch) Wide EVF (About 1,560,000 dots) (For Europe) 0.24-inch Wide EVF (About 1,560,000 dots) (For North America / Asia) |
| Manual Ring | Focus / Zoom or Iris |
| Accessory Shoe | Yes |
| LED Video Light | Average Illumination: Approx. 70 lx (1.0m) |
| Irradiation Angle: Approx. 30° | |
| Color Temperature: Approx. 4600K | |
| INTERFACE SECTION | |
| Video | SDI OUT: BNC x 1, 0.8V[p-p], 75Ω, 3G/1.5G HD-SDI supported Output format: 1080/59.94p LEVEL-A/50.00p LEVEL-A, 1080/29.97PsF/25.00PsF/23.98PsF, 1080/59.94i/50.00i, 720/59.94p/50.00p |
| HDMI: Type A x 1 (VIERA Link not supported) Output format: 2160/59.94p/50.00p/29.97p/25.00p/23.98p, 1080/59.94p/50.00p/29.97p/25.00p/23.98p/59.94i/50.00i, 720/59.94p/50.00p, 480/59.94p, 576/50.00p | |
| Audio Input | Built-in Microphone: Stereo microphone |
| Microphone Input: 3.5mm stereo mini jack x 1 | |
| XLR Input: XLR (3 pins) x 2 Input high impedance, LINE/MIC/MIC+48 V (switchable SW) LINE: +4dBu/0dBu (switchable menu) MIC: -40dBu/-50dBu/-60dBu (switchable menu) | |
| Audio Output | SDI: 2 ch (LPCM 24bit) Gain: 0dB/-6dB/-8dB |
| HDMI: 2 ch (LPCM 24bit) | |
| Headphone: 3.5 mm diameter stereo mini jack x 1 | |
| Speaker: 15 mm diameter, round x 1 | |
| Other Input/Output | Camera Remote: 2.5mm super mini jack x 1 |
| USB 2.0 HOST: Micro-AB connector, 5-pin, only USB LAN conversion supported | |
| USB 2.0 DEVICE: Micro-AB connector, 5-pin, mass storage function (read only) | |
| DC IN: DC 12V (11.4V – 12.6V) EIAJ Type4 | |
| Wi-Fi | |
| Standard | IEEE 802.11b/g/n |
| Frequency | 2.4GHz band |
| STANDARD ACCESSORY | |
| AC Adaptor | Yes |
| AC Cable | Yes |
| Rechargeable Battery Pack | Yes (5,900mAh) |
| Handle Unit | Yes (detachable) |
| Battery Charger | – |
| IR Remote | – |
| HDMI Cable | – |
| AV Cable | – |
| USB Cable | Yes (Micro-AB to Host) |
| USB LAN Conversion Adaptor | Yes (VW-UEA1) |
| Microphone Holder | Yes |
| Microphone Holder Screws | Yes |
| Input Terminal Cap | – |
| Eye Cup | Yes |
| Lens Hood | Yes |
| Editing Software | – |
* Only images cut from video in video playback mode are supported.
Note: Specifications are subject to change without notice.
