General
|
Power:
|
DC 7.28 V (when the battery is used)
DC 12 V (when the AC adaptor is used)
|
Power Consumption:
|
17 W (when the LCD monitor is used)
11.5 W (1080i / 422ALL-I 100M recording, when the LCD monitor is used, no external device connection)
|
Operating Temperature:
|
0 ?C to 40 ?C (32 ?F to 104 ?F)
|
Operating Humidity:
|
10 % to 80 % (no condensation)
|
Weight:
|
Body: approx. 1.9 kg (4.19 lb)
(body only, excluding lens hood, battery, and accessories)
Shooting: approx. 2.3 kg (5.07 lb)
(including lens hood, battery, and microphone holder)
|
Dimensions:
|
180 mm (W) x 173 mm (H) x 311 mm (D)
(7-1/8 inches x 6-13/16 inches x 12-1/4 inches)
(excluding protrusion and eye cup)
|
Camera Unit
|
Pickup Device:
|
1.0-type (effective size) MOS solid state image sensor
|
Effective Pixels:
|
15,030,000 pixel
|
Lens:
|
Optical image stabilizer lens, optical 20x motorized zoom
F value: F2.8 to F4.5
Focal length: f=8.8 mm to 176 mm
35 mm equivalent: 24.5 mm to 490 mm
Filter Diameter: 67 mm
ND Filter: Clear, 1/4, 1/16, 1/64
IR Filter: Incorporates the ON/OFF control function
Shortest Shooting Distance (M.O.D.):
Approx. 10 cm (W), 1.0 m (T) from the front lens
|
Gain Setting:
|
L/M/H selector switch
?3 dB to 18 dB (Adjustable in 1 dB steps)
24dB, 30 dB, 36 dB switched
(when assigning [S. GAIN] to the USER button)
|
Color Temperature Setting:
|
ATW, ATW LOCK, A ch, B ch, preset 3200 K/preset 5600 K/VAR (2000 K to 15000 K)
|
Shutter Speed:
|
When [SYSTEM MODE] = 59.94 Hz
? 59.94i/59.94p mode:
1/60 sec. (shutter off), 1/100 sec., 1/120 sec., 1/250 sec., 1/500 sec., 1/1000 sec., 1/2000 sec., 1/4000 sec., 1/8000 sec., 1/10000 sec.
? 29.97p mode:
1/30 sec., 1/50 sec. (shutter off), 1/60 sec., 1/100 sec., 1/120 sec., 1/250 sec., 1/500 sec., 1/1000 sec., 1/2000 sec., 1/4000 sec., 1/8000 sec., 1/10000 sec.
? 23.98p mode:
1/24 sec., 1/48 sec., 1/50 sec. (shutter off), 1/60 sec., 1/100 sec., 1/120 sec., 1/250 sec., 1/500 sec., 1/1000 sec., 1/2000 sec., 1/4000 sec., 1/8000 sec., 1/10000 sec.
When [SYSTEM MODE] = 50.00 Hz
? 50i/50p mode:
1/50 sec. (shutter off), 1/60 sec., 1/100 sec., 1/120 sec., 1/250 sec., 1/500 sec., 1/1000 sec., 1/2000 sec., 1/4000 sec., 1/8000 sec., 1/10000 sec.
? 25p mode:
1/25 sec., 1/50 sec. (shutter off), 1/60 sec., 1/100 sec., 1/120 sec., 1/250 sec., 1/500 sec., 1/1000 sec., 1/2000 sec., 1/4000 sec., 1/8000 sec., 1/10000 sec.
|
Shutter Speed:
(Slow Shutter)
|
When [SYSTEM MODE] = 59.94 Hz
? 59.94i/59.94p mode: 1/1 sec., 1/2 sec., 1/4 sec., 1/6 sec., 1/15 sec., 1/30 sec.
? 29.97p mode: 1/1 sec., 1/2 sec., 1/4 sec., 1/6 sec., 1/15 sec.
? 23.98p mode: 1/1 sec., 1/2 sec., 1/4 sec., 1/6 sec., 1/12 sec.
When [SYSTEM MODE] = 50.00 Hz
? 50i/50p mode: 1/1 sec., 1/2 sec., 1/4 sec., 1/6 sec., 1/12 sec., 1/25 sec.
? 25p mode: 1/1 sec., 1/2 sec., 1/4 sec., 1/6 sec., 1/12 sec.
|
Shutter Speed:
(Synchro Scan)
|
When [SYSTEM MODE] = 59.94 Hz
? 59.94i/59.94p mode: 1/60.0 sec. to 1/7200 sec.
? 29.97p mode: 1/30.0 sec. to 1/7200 sec.
? 23.98p mode: 1/24.0 sec. to 1/7200 sec.
When [SYSTEM MODE] = 50.00 Hz
? 50i/50p mode: 1/50.0 sec. to 1/7200 sec.
? 25p mode: 1/25.0 sec. to 1/7200 sec.
|
Shutter Open Angle:
|
3.0 deg to 180.0 deg to 360.0 deg (in 0.5 deg steps)
|
VFR Recording Frame Rate:
|
When [SYSTEM MODE] = 59.94 Hz
1, 2, 4, 6, 9, 12, 15, 18, 20, 21, 22, 24, 25, 26, 27, 28, 30, 32, 34, 36, 40, 44, 48, 54, 60 (fps)
When [SYSTEM MODE] = 50.00 Hz
1, 2, 4, 6, 9, 12, 15, 18, 20, 21, 22, 23, 24, 25, 26, 27, 28, 30, 32, 34, 37, 42, 45, 48, 50 (fps)
|
Super Slow Recording:
|
When [SYSTEM MODE] = 59.94 Hz
1920 x 1080 (FHD): shooting frame rate 120 fps
When [SYSTEM MODE] = 50.00 Hz
1920 x 1080 (FHD): shooting frame rate 100 fps
|
Sensitivity:
|
When [HIGH SENS.] mode
F12 (2000 lx, 3200 K, 89.9 % reflect, 2160/59.94p, 1080/59.94i)
F13 (2000 lx, 3200 K, 89.9 % reflect, 2160/50p, 1080/50i)
|
Horizontal Resolution:
|
2000 TV or higher (UHD: center)
1000 TV or higher (FHD: center)
|
i.Zoom:
|
?32 (FHD), ?24 (UHD)
|
Digital Zoom:
|
?2/?5/?10
|
Lens Hood:
|
Hood with lens cover
|
Memory Card Recorder
|
Recording Media:
|
SDHC memory card (4 GB to 32 GB),
SDXC memory card (32 GB to 128 GB)
UHS-I/UHS-II UHS Speed Class3 supported, Video Speed Class V90 supported
microP2 card (A series, B series)
Please see back cover for the ?Available Memory Card? table.
|
Recording Slot:
|
microP2/SDXC UHS-II card slot x 2
|
Recording Pixels:
|
3840 ? 2160 (UHD), 1920 ? 1080 (FHD), 1280 ? 720 (HD), 720 ? 480(SD), 720 ? 576 (SD)
|
System Frequency:
|
59.94 Hz/50.00 Hz
|
Recording File Format:
|
MOV (AVC), MOV (HEVC), AVCHD
|
Recording Format:
|
Please see page 4 for the ?Recording Format? table.
|
Recording Time:
|
Please see back cover for the ?Recording Time? table.
|
2 Slot Functions:
|
Relay Rec, Simultaneous Rec, Background Rec
|
Special Recording Functions:
|
Pre Rec, Interval Rec, Time Stamp
|
Digital Video
|
Quantization:
|
MOV: 4:2:2 10 bit/4:2:0 8 bit/4:2:0 10 bit (HEVC)
AVCHD: 4:2:0 8 bit
|
Video Compression Format:
|
H.264/MPEG-4 AVC High Profile
H.265/MPEG-H HEVC Main10 Profile
|
Digital Audio
|
Recording Audio Signal:
|
MOV: 48 kHz/24 bit, 2 ch, Linear PCM
AVCHD: 48 kHz/16 bit, 2 ch, Dolby Audio?
|
Headroom:
|
12 dB/18 dB/20 dB switchable (menu)
|
Live Streaming
|
Video Compression Format:
|
H.264/MPEG-4 AVC Main Profile, High Profile
|
Audio Compression Format:
|
AAC-LC
|
Network Protocol:
|
RTSP/RTP/RTMP
|
Video Output
|
SDI OUT:
|
BNC x 1, SDI REC REMOTE supported
HD: 0.8 V [p-p], 75 ? SD: 0.8 V [p-p], 75 ?, Output format (4:2:2 10 bit):
? 1920 ? 1080: 59.94p, 50p, 59.94i, 50i, 29.97Psf, 25Psf, 23.98PsF
? 1280 ? 720: 59.94p, 50p
? 720 ? 480: 59.94i ? 720 ? 576: 50i
|
HDMI OUT :
|
HDMI x 1, Type A, HDMI REC REMOTE supported, VIERA Link not supported
Output format (4:2:2 10 bit):
? 3840 ? 2160: 59.94p, 50p, 29.97p, 25p, 23.98p
? 1920 ? 1080: 59.94p, 50p, 59.94i, 50i, 29.97p, 25p, 23.98p
? 1280 ? 720: 59.94p, 50p
? 720 ? 480: 59.94p ? 720 ? 576: 50p
|
VIDEO OUT:
|
3.5 mm diameter mini jack, composite 1.0 V [p-p], 75 ?
|
Audio Input/Output
|
Built-in Microphone:
|
Stereo microphone
|
Input 1/2:
|
XLR (3-pin) x 2 (INPUT1, INPUT2)
Input high impedance, LINE/MIC/MIC+48V (switchable SW)
MIC: ?40 dBu/?50 dBu/?60 dBu (switchable menu)
LINE: +4 dBu/0 dBu (switchable menu)
|
SDI OUT:
|
Linear PCM 2 ch
|
HDMI OUT:
|
Linear PCM 2 ch
|
Headphone:
|
3.5 mm diameter stereo mini jack x 1
|
AV OUT:
|
3.5 mm diameter stereo mini jack x 1, Output level: 600 ?, 316 mV
|
Speaker:
|
20 mm diameter, round x 1
|
Other Input/Output
|
TC IN/OUT:
|
BNC x 1,
Used as the input and output terminals (switchable menu)
Input: 1.0 V to 4.0 V [p-p] 10 K?
Output: 2.0 V ? 0.5 V [p-p] low impedance
|
REMOTE:
|
2.5 mm diameter super mini jack
|
LAN:
|
RJ-45: 1000BASE-T/100BASE-TX/10BASE-T
|
USB 2.0 HOST:
|
Type-A, 4-pin (5 V, 0.5 A) for Wireless Module (option)
|
USB 3.0 DEVICE:
|
USB 3.1 GEN1 Type-C, USB Mass storage function
No USB bus power function
|
DC IN 12V:
|
DC 12 V EIAJ Type 4
|
Monitor/Viewfinder
|
LCD Monitor:
|
3.5 type TFTLCD color monitor (3:2),
approx. 1,620,000 dots, Touch panel
video display (16: 9) area: Approx. 1,370,000 dots
|
Viewfinder:
|
0.39 type OLED (organic EL display), approx. 2,360,000 dots,
video display (16: 9) area: approx. 1,770,000 dots
|
