Portkeys BM5IV 5.5″ 2000nit HDMI/SDI Touchscreen Monitor

SGD 801.45 excl. Tax

Product Highlights:

  • 5.5-inch, 10-bit (8+2 FRC) panel
  • Daylight-viewable with a maximum brightness of 2,000 nits.
  • Professional monitoring tools: waveform, vectorscope, peaking, ARRI false color.
  • 3D LUT monitoring and 3D LUT SDI output capabilities.
  • Wired camera control for RED, Sony, Canon, Panasonic, BMD, and ZCAM E2.
  • Built-in Sony NP-F style battery plate.
Weight 6 kg
SKU: BM5 IV Category:
Description
Click to rate this post!
[Total: 1 Average: 5]

Portkeys BM5IV 5.5-inch Wide Color Gamut 2000 nit HDMI/SDI On-Camera Touchscreen Monitor

The Portkeys BM5IV is a lightweight, rugged 5.5-inch Wide Color Gamut on-camera monitor with 2,000 units of brightness, HDMI/SDI video input and output ports, and wired camera control capabilities.

  • 5.5-inch, 10-bit (8+2 FRC) panel with a resolution of 1920 x 1080 and a 1000:1 contrast ratio.
  • Daylight-viewable with a maximum brightness of 2,000 nits.
  • 1 x 4K60P HDMI input, 1 x 3G-SDI input, 1 x 4K60P HDMI output, 1 x 3G-SDI output with cross-conversion.
  • Powered by CINENORM OS, which supports up to 7 custom pages.
  • Professional monitoring tools: waveform, vectorscope, peaking, ARRI false color.
  • 3D LUT monitoring and 3D LUT SDI output capabilities.
  • Split-screen monitoring capabilities with multiple viewing modes, including PBP, PIP, and H2V.
  • Factory color-calibrated and the possibility for users to create a 3D calibration LUT with an X-Rite color probe.
  • Wired camera control for RED, Sony, Canon, Panasonic, BMD, and ZCAM E2.
  • TILTA Nucleus N/M Wireless follows focus wired control.
  • Built-in Sony NP-F style battery plate.
  • 4-pin 7.4V-24V power inputs for external power (D-Tap cable included).
  • Lightweight and rugged aluminum housing: only 358g/12.62oz.

Read Our Blog:

Specifications
Click to rate this post!
[Total: 1 Average: 5]

Basic parameters:

  • Screen size: 5.5″
  • Material: Aluminum alloy
  • Brightness: 2000nits
  • Dimension: 145.4×91.4×39.6mm
  • Input voltage: 7~24V
  • Resolution: 1920×1080
  • Color depth: 10bit (8+2FRC)
  • Audio output: 3.5mm Headphone jack
  • Viewing angle: 178°H/178°V
  • Weight: 350g
  • Maximum power: 16W
  • Contrast ratio: 1000:1
  • Fan: Yes
  • Support battery model: NP-F970/F960/F750/F550
  • Camera control interface: Remote
  • Power input: 4-pin aviation connector
  • Signal output: 3G SDI, HDMI
  • Signal input: 3G SDI, HDMI
  • Operating system: CINENORM OS
  • OSD Languages: English/Français/español
  • TILTA nucleus control interface: UART
  • Signal conversion: HDMI/SDI Conversion
  • USB-A: Upgrade firmware / Load LUT
In The Box
Click to rate this post!
[Total: 1 Average: 5]
  • BM5IV Monitor
  • Safety box
  • D-Tap to 4-pin aviation connector power cable
  • Micro USB flash stick
  • Customer feedback card
