EK 100 G4
|
|
Frequency range
|
A1: 470-516 MHz
A: 516-558 MHz
GB: 606-648 MHz
G: 566-608 MHz
B: 626-668 MHz
C: 734-776 MHz
D: 780-822 MHz
E: 823-865 MHz
|
|
Dimensions
|
Approx. 82 x 64 x 24 mm
|
|
Compander
|
Sennheiser HDX
|
|
THD, total harmonic distortion
|
≤ 0.9 %
|
|
Weight
|
Approx. 160 g
|
|
Audio output
|
3.5 mm jack socket: +12 dBu (mono, unbalanced)
|
|
Signal-to-noise ratio
|
> 110 dBA
|
|
Switching bandwidth
|
up to 42 MHz
|
|
Peak deviation
|
±48 kHz
|
|
Nominal deviation
|
±24 kHz
|
|
Modulation
|
Wideband FM
|
|
Operating Time
|
Typically 8h
|
|
Power supply
|
2 AA batteries, 1.5 V or BA 2015 accupack
|
|
Current consumption
|
at nominal voltage: typ. 180 mA
with receiver switched off: ≤ 25 µA
|
|
Adjacent channel rejection
|
≥ 65 dB
|
|
Intermodulation attenuation
|
≥ 65 dB
|
|
Powering
|
3 V battery / 2.4 V rechargeable battery
|
|
Receiving frequency
|
Max. 1680 receiving frequencies, adjustable in 25 kHz steps 20 frequency banks, each with up to 12 factory-preset channels, no intermodulation 1 frequency bank with up to 12 programmable channels
|
|
RF sensitivity
|
< 1.6 μV for 52 dBA eff S/N
|
|
Squelch
|
low: 5 dBµV middle: 15 dBµV high: 25 dBμV
|
|
Temperature Range
|
-10 °C to +55 °C
|
|
Receiver Principle
|
Adaptive diversity
|
|
Blocking
|
≥ 70 dB
|
|
SK 100 G4
|
|
Dimensions
|
Approx. 82 x 64 x 24 mm
|
|
Compander
|
Sennheiser HDX
|
|
THD, total harmonic distortion
|
≤ 0.9 %
|
|
Weight
|
(incl. batteries) approx. 160 g
|
|
Signal-to-noise ratio
|
≥ 110 dBA
|
|
RF output power
|
Max. 30 mW
|
|
Switching bandwidth
|
up to 42 MHz
|
|
Peak deviation
|
±48 kHz
|
|
Nominal deviation
|
±24 kHz
|
|
Operating time
|
Typically 8 h
|
|
Modulation
|
Wideband FM
|
|
Power supply
|
2 AA batteries, 1.5 V or BA 2015 accupack
|
|
Current consumption
|
at nominal voltage: typ. 180 mA
with transmitter switched off: ≤ 25 µA
|
|
Input impedance
|
40 kΩ, unbalanced / 1 MΩ
|
|
Max. Input voltage
|
3 Veff
|
|
Powering
|
3 V battery / 2.4 V rechargeable battery
|
|
Transmission frequency
|
Max. 1680 transmitting frequencies, adjustable in 25 kHz steps 20 frequency banks, each with up to 12 factory-preset channels, no intermodulation 1 frequency bank with up to 12 programmable channels
|
|
AF frequency response
|
Mic: 80 – 18,000, Hz Line: 25 – 18,000 Hz
|
|
Temperature Range
|
-10 °C to +55 °C
|
|
Frequency stability
|
≤ ±15 ppm
|
|
SKP 100 G4
|
|
Dimensions
|
Approx. 105 x 43 x 43 mm
|
|
Compander
|
Sennheiser HDX
|
|
THD, total harmonic distortion
|
≤ 0.9 %
|
|
Weight
|
(incl. batteries) approx. 195 g
|
|
Signal-to-noise ratio
|
≥ 110 dBA
|
|
RF output power
|
Max. 30 mW
|
|
Switching bandwidth
|
up to 42 MHz
|
|
Peak deviation
|
±48 kHz
|
|
Nominal deviation
|
±24 kHz
|
|
Operating time
|
Typically 8 h
|
|
Modulation
|
Wideband FM
|
|
Power supply
|
2 AA batteries, 1.5 V or BA 2015 accupack
|
|
Current consumption
|
at nominal voltage: typ. 180 mA
with transmitter switched off: ≤ 25 µA
|
|
Imput Impedance
|
68 kΩ, unbalanced
|
|
Max. Input voltage
|
3.3 Veff
|
|
Powering
|
3 V battery / 2.4 V rechargeable battery
|
|
Transmission frequency
|
Max. 1680 transmitting frequencies, adjustable in 25 kHz steps 20 frequency banks, each with up to 12 factory-preset channels, no intermodulation 1 frequency bank with up to 12 programmable channels
|
|
AF frequency response
|
80 – 18,000 Hz
|
|
Temperature Range
|
-10 °C to +55 °C
|
|
Frequency stability
|
≤ ±15 ppm
|
|
ME 2
|
|
Connector
|
3.5 mm jack
|
|
Frequency response
|
50 to 18,000 Hz (ME 2-II)
|
|
Max. sound pressure level
|
130 dB
|
|
Cable length
|
approx. 1.60 m
|
|
Transducer principle
|
pre-polarized condensor microphone
|
|
Pick-up pattern
|
omni-directional
|
|
Sensitivity in free field, no load (1kHz)
|
20 mV/Pa
|
|
Equivalent noise level
|
36 dB
|
