Name: Sennheiser SR IEM G4 Wireless In-Ear Monitor Transmitter
SKU: 28294
Price: 622.00 USD
Availability: InStock

Sennheiser SR IEM G4 Wireless In-Ear Monitor Transmitter

USD 622.00 excl. Tax

Weight

N/A

Choose Product Variant

SR IEM G4-A (516-558 MHz Ch26-Ch31), SR IEM G4-B (626-668 MHz Ch40-Ch45), SR IEM G4-C (734-776 MHz Ch54-Ch59), SR IEM G4-D (780-822 MHz Ch59-Ch64), SR IEM G4-E (823-865 MHz Ch65-Ch70), SR IEM G4-G (566-608 MHz Ch33-Ch38)

SKU: N/A Category: VHS/UHS

Description
Features
Specifications
In the Box
Delivery Info
Reviews (0)

Description

Sennheiser SR IEM G4 – Wireless In-Ear Monitor Transmitter for professional live sound applications

Sennheiser SR IEM G4 Wireless In-Ear Monitor Half-rack stereo transmitter in a full-metal housing with OLED display for full control delivering clarity along the whole frequency spectrum for daily use on stage with evolution wireless G4 In Ear Monitoring systems.

Features

Half-rack stereo transmitter in a full-metal housing with OLED display for full control
Easy and flexible wireless synchronization between transmitter and receiver via infrared
Compatible with Sennheiser WSM control software for flexible frequency allocation
Up to 16 compatible channels
Up to 42 MHz bandwidth with 1680 selectable frequencies, fully tunable in a stable UHF range
Transmission Range: up to 100 meters / 300 feet
High RF output power (up to 50 mW) depending on country regulations
Compatible with wireless speaker system LSP 500 PRO

Specifications

SR IEM G4
Frequency range	A1: 470-516 MHz A: 516-558 MHz GB: 606-648 MHz G: 566-608 MHz B: 626-668 MHz C: 734-776 MHz D: 780-822 MHz E: 823-865 MHz
Dimensions	Approx. 202 x 212 x 43 mm
Compander	Sennheiser HDX
THD, total harmonic distortion	≤ 0.9 %
Weight	Approx. 980 g
Audio input	2x XLR-3/¼" (6.3 mm) jack combo socket, electronically balanced
Audio output	¼" (6.3 mm) stereo jack socket, balanced
Signal-to-noise ratio	> 90 dB
RF output power	switchable: Low: typ. 10 mW, Standard: typ. 30 mW, High: typ. 50 mW
Switching bandwidth	up to 42 MHz
Peak deviation	±48 kHz
Nominal deviation	±24 kHz
Modulation	Wideband FM stereo (MPX pilot tone)
Power supply	12 V DC
Current consumption	max. 350 mA
Max. Input voltage	+22 dBu
Transmission frequency	Max. 1680 frequencies, adjustable in 25 kHz steps, 20 frequency banks, each with up to 16 factory-preset channels, no intermodulation, 6 frequency banks with up to 16 programmable channels
AF frequency response	25 Hz to 15 kHz
Temperature Range	-10 °C to +55 °C
Frequency stability	±10 ppm
Antenna Output	BNC socket, 50 Ω

In the Box

SR IEM G4 stereo transmitter
rod antenna
power supply
GA 3 rackmount set
quick guide
safety guide
manufacturer declaration sheet
