Display |
Panel Type |
LCD |
Size Diagonal |
7 |
Resolution |
1920 x 1080 |
Pixel Density (PPI) |
323 |
Aspect Ratio |
16:10 Native |
Active Area |
7.0 in |
Brightness |
1000 nits |
Contrast |
1000:1 |
Colour Gamut |
85% NTSC (100% Rec 709) |
Colour Depth |
24 Bit (8bpc) |
Viewing Angle |
Full 179 Degrees |
Backlight Type |
LED |
Adjustable Backlight |
Yes |
Temperature Adaptive Colour |
Yes |
Input Signal |
3G-SDI |
1080p50, 1080p59.94, 1080p60, 1080i100, 1080i119.88, 1080i120 |
HD-SDI |
RGB/YCC 4:2:2 and 4:4:4, 1080p60, 1080i60,1080i59.94,1080i50, 1080p30, 1080p25, 1080p24, 1080p23.98, 1080pSF23.98, |
1080pSF24, 1080pSF25 , 1080pSF29.97, 720p60, 720p59.94, 720p50 |
SD-SDI |
YCC 4:2:2 @ 10-bits: 480i29.97, 576i25 |
HDMI |
Supports 8/10/12 bit color, 1080p60, 1080p59.94, 1080p50, 1080i60, 1080i59.94, 1080i50, 1080p30, 1080p25, 1080p24, 1080p23.98, |
1080pSF23.98, 1080pSF24, 1080pSF25, 1080pSF30, 720p60, 720p59.94 , 720p50 |
Component |
Not Supported |
Composite |
Not Supported |
Audio |
HDMI and SDI |
Output Signal |
3G-SDI |
YCC 4:2:2 1080p60, 1080p59.94, 1080p50, 1080i120, 1080i119.88, 1080i100 all at 8 bits |
HD-SDI |
RGB/YCC 4:2:2 and 4:4:4, 1080p60, 1080i60,1080i59.94,1080i50, 1080p30, 1080p25, 1080p24, 1080p23.98, 1080pSF23.98, |
1080pSF24, 1080pSF25 , 1080pSF29.97, 720p60, 720p59.94, 720p50 |
SD-SDI |
YCC 4:2:2 @ 10-bits: 480i29.97, 576i25 |
HDMI |
Supports 8/10/12 bit color, 1080p60, 1080p59.94, 1080p50, 1080i60, 1080i59.94, 1080i50, 1080p30, 1080p25, 1080p24, 1080p23.98, |
1080pSF23.98, 1080pSF24, 1080pSF25, 1080pSF30, 720p60, 720p59.94 , 720p50 |
Component |
Not Supported |
Composite |
Not Supported |
Audio |
Not Supported |
Connector Type |
SDI |
1 SDI (in), 1 SDI (out) |
HDMI |
1 HDMI (in), 1 HDMI (out) |
Component |
Not Supported |
Composite |
Not Supported |
Audio |
1/8in Mini Stereo Headphone |
Power In |
LP-E6 style / Sony L style |
Power Out |
LP-E6 style / Sony L style |
USB |
Micro-USB 5V @ .5A |
Controls |
Primary Control Interface |
Joystick + “Back” button |
Record/Capture |
Capture button |
User Defined Functions |
Uses “Pages” in conjunction with the Joystick control to provide any number of user defined monitoring options. |
RF Wireless Remote / External Control |
Via Remote |
Data I/O |
Storage |
SD Card (full-size) |
USB |
Factory use and Future user functionality |
Environmental |
Compliance |
CE, FCC, IC |
Operating Temperature |
30F to 90F |
Storage Temperature |
0F to 120F |
Screen Protection |
1mm Acrylic (user replaceable) |
Height |
4.23″ (10.74cm) |
Width |
7.56″ (19.20cm) |
Depth/Length |
.95″ (2.41cm) |
Weight (Item Only without battery) |
17oz (481.94g) |
Weight (Packaged) |
29.6oz (839.14g) |
Mount Points |
(4) ¼-20 thread points (bottom, back & sides) |
Software |
Pixel Zoom (type) |
2x & 4x with smooth pan via joystick |
Frame Guides |
Preset Aspect Ratios & Customizable |
DSLR Scale |
Canon 5DMkii & Canon 7D |
Custom Scale |
Underscan Only |
Anamorphic De-Squeeze |
1.33x, 1.5x, 1.66x, 2.0x |
Image Rotate(Manual/Automatic) |
Automatic or Manual Control |
Image Flip (Manual/Automatic) |
Automatic or Manual Control |
Cross Conversion |
Yes |
Focus Assist (Colours) |
User Adjustable Color Style and Intensity |
Peaking |
User Adjustable Intensity |
False Colour |
Spectrum, Arri Style and Fully User Customizable |
Zebra |
Dual – User Configurable |
Waveform |
Luma & RGB Style, Fully User Customizable w/ Region of Interest Highlighting |
Vectorscope |
Yes |
PIP |
No |
RGB Parade |
Fully User Customisable |
Histogram |
Luma & RGB Style |
Horizon Indicator |
No |
Image Capture |
With Dedicated Button and Image Gallery |
Custom LUTS |
Loadable as Looks on Pages or as Systemwide Color Calibration via the settings menu |
LUT Creation |
No |
LUT Downstream |
Applied on Output Preview Page |
LUT Import |
Via SD Card or USB Storage Device |
Image Overlay |
Opacity Slider and Blink Setting |
Blue Only |
No |
Firmware |
User Upgradable. Current Version: 2.0 |
Audio Meters |
Up to 8 channel |
