Sony PXW-FS7K 4K XDCAM
Sony PXW-FS7 4K Super 35mm Exmor CMOS sensor XDCAM
Sony PXW-FS7 4K Super 35mm Exmor CMOS sensor XDCAM
Sony PXW-FS7 4K Super 35mm Exmor CMOS sensor XDCAM
Click to enlarge

Sony PXW-FS7K 4K Super 35mm Exmor CMOS sensor with Built-in Multi-Interface (MI) Shoe

USD 8,490.00 excl. Tax

  • Super Slow Motion continuous recordings
  • Easy settings during one-man operation
  • Dust-proof, drip-proof design
  • Built-in Multi-Interface (MI) Shoe
Weight8 kg
Add to wishlist
SKU: PXW-FS7K Categories: ,
Description

Sony PXW-FS7K 4K Super 35mm Exmor CMOS sensor

Achieve great shots at a low value with the Sony PXW-FS7K. The new features of this handy camcorder include a 4K Super 35mm Exmor CMOS sensor that has an ergonomic design making it highly and easily adaptable to its functionality.

It consumes lower power as compared to the average camcorders and has an easy settings menu, perfect for professionals and non-professional.

Not to mention it has the ability to record super slow motions continuously and its dust proof so that you can use it outdoor and don’t have to worry about cleaning your lens. Take great fast action shots with this camcorder.

Some improved features of this model include:
  • Stability and operability particularly in Iris Setting, Iris Dial and Assignable dial.
  • Video signal monitor
  • Support for Interval Recording, 2K Full and 2K Centre in Image Scan Mode Setting.
  • Improved Focus Magnification and FS-RAW image quality operation and stability.
  • You can also expand to 0% the lowest value of Zebra.
Main Features

With the Sony PXW-FS7K, you no longer need to call or hire help just to record a perfect shot. This camcorder is known for its ease of setting and using and is classified as a one-man operation camera.

On the side of the camera, you will find the Zebra function, Peaking buttons, and contrast knob as well, making it easy to adjust the focus, exposure, and contrast while taking pictures. You can also set the position of the finder by a simple action of turning a single knob.

The grip provided by the Sony PXW-FS7K allows for easy operability and handling. You don’t have to worry about dropping your camcorder or having it slipping off no longer.

This design was reached after numerous consultations with cinematographers and videographers and had a few prototypes produced before the release of the final design in the market, so you know it’s the real deal.

The shape is great for using the camera for long periods, and users can grip the camera in different styles. There are programmable buttons on the grip for ease and fast use, and these include the Zoom button, Rec Start/Stop, and expanded focus function buttons. It is easy to adjust the length of the arm by a simple adjustment of the knob which allows for adjustments of the camera angle hence making it easy to choose a comfortable style for using the camera.

Extended Support

The Sony PXW-FS7K supports some unique formats including XAVC Long and Intra-GOP, which allow for HD recording in different codecs such as the H.264AVC and MPEG2 HD.

The Sony PXW-FS7K camera comes equipped with an XDCA-F57 extension unit meant to offer support during shooting ,allows for different shooting styles and an easy workflow. To support 4K motion picture shooting and Super Slow Motion,the Sony PXW-FS7 is equipped with a Super 35mm CMOS image sensor that allows for the shooting of a 4352×2662 image quality. Connect your camera to a wireless microphone using a Multi- Interface (MI) Shoe.

Another support feature available with this model is an E-mount lens mount, and this is perfect for those intending to use the camera to shoot a movie or motion-pictures.

Be a director, in the comfort of your home or anywhere you like at a bargain price. Who knows, you may be the next famous director.

Features
  • Lightweight ergonomic design and low power consumption
  • High-sensitivity 4K Super 35mm Exmor CMOS sensor
  • Super Slow Motion continuous recordings
  • Easy settings during one-man operation
  • Dust-proof, drip-proof design
  • Built-in Multi-Interface (MI) Shoe
  • Internal recording in 4K* resolution up to 60fps
Specifications
General
Mass
Approx 2.0 kg (body only)
Approx. 4.5 kg (with Viewfinder, Eyepiece, Grip Remote Control, BP-U30 battery, SELP28135G LENS, an XQD memory card)
Dimensions (W x H x D) *1
156 x 239 x 247 mm (body without protrusions)
Power Requirements
DC 12 V
Power Consumption
Approx. 19W (while recording XAVC-I QFHD 59.94P, SELP28135G Lens, Viewfinder ON, not using external device)
Operating Temperature
0°C to 40°C
32°F to 104°F
Storage Temperature
-20°C to +60°C
-4°F to +140°F
Battery Operating Time
Approx. 1 hrs with BP-U30 battery (while recording XAVC-I QFHD 59.94P, SELP28135G Lens, Viewfinder ON, not using external device)
Approx. 2 hrs with BP-U60 battery while recording XAVC-I QFHD 59.94P, SELP28135G Lens, Viewfinder ON, not using external device)
Approx. 3 hrs with BP-U90 battery (while recording XAVC-I QFHD 59.94P, SELP28135G Lens, Viewfinder ON, not using external device)
Recording Format (Video)
XAVC-I mode: 4K 59.94P VBR, bit rate 600Mbps, MPEG-4 H.264/AVC
XAVC-I mode: 4K 50P VBR, bit rate 500Mbps, MPEG-4 H.264/AVC
XAVC-I mode: 4K 29.97P VBR, bit rate 300Mbps, MPEG-4 H.264/AVC
XAVC-I mode: 4K 23.98P VBR, bit rate 240Mbps, MPEG-4 H.264/AVC
XAVC-I mode: 4K 25P VBR, bit rate 250Mbps, MPEG-4 H.264/AVC
Recording Format (Video)
XAVC-I mode:QFHD 59.94P CBG, bit rate 600Mbps, MPEG-4 H.264/AVC
XAVC-I mode:QFHD 50P CBG, bit rate 500Mbps, MPEG-4 H.264/AVC
XAVC-I mode:QFHD 29.97P CBG, bit rate 300Mbps, MPEG-4 H.264/AVC
XAVC-I mode:QFHD 23.98P CBG, bit rate 240Mbps, MPEG-4 H.264/AVC
XAVC-I mode:QFHD 25P CBG, bit rate 250Mbps, MPEG-4 H.264/AVC
XAVC-I mode:HD 59.94P VBR, maximum bit rate 222Mbps, MPEG-4 H.264/AVC
XAVC-I mode:HD 50P VBR, maximum bit rate 185Mbps, MPEG-4 H.264/AVC
XAVC-I mode:HD 59.94i VBR, maximum bit rate 111Mbps, MPEG-4 H.264/AVC
XAVC-I mode:HD 50i VBR, maximum bit rate 112Mbps, MPEG-4 H.264/AVC
XAVC-I mode:HD 29.97P VBR, maximum bit rate 111Mbps, MPEG-4
Recording Format (Video)
XAVC-L QFHD 59.94P/50P mode: VBR, maximum bit rate 150Mbps, MPEG-4 H.264/AVC
XAVC-L QFHD 29.97P/23.98P/25P mode: VBR, maximum bit rate 100Mbps, MPEG-4 H.264/AVC
XAVC-L HD 50 mode: VBR, maximum bit rate 50Mbps, MPEG-4 H.264/AVC
XAVC-L HD 35 mode: VBR, maximum bit rate 35Mbps, MPEG-4 H.264/AVC
XAVC-L HD 25 mode: VBR, maximum bit rate 25Mbps, MPEG-4 H.264/AVC

MPEG HD422 mode: CBR, maximum bit rate 50Mbps, MPEG-2 422P@HL
Apple ProRes 422 HQ: VBR, maximum bit rate 220Mbps, 4:2:2 10 bit
ProRes 422*2
Apple ProRes 422: VBR, maximum bit rate 147Mbps, 4:2:2 10 bit

Recording Format (Audio)
LPCM 24 bits, 48 kHz, 4 channels (Recording/Playback ONLY 2channels)
Recording Frame Rate
XAVC-I QFHD mode: 3840×2160/ 59.94P, 50P, 29.97P, 23.98P, 25P
XAVC-I HD mode: 1920×1080/59.94P, 50P, 59.94i, 50i, 29.97P, 23.98P, 25P

XAVC-L QFHD mode: 3840×2160/59.94P, 50P, 29.97P, 23.98P, 25P
XAVC-L HD 50 mode: 1920×1080/59.94P, 50P, 59.94i, 50i, 29.97P, 23.98P, 25P
XAVC-L 35 mode: 1920×1080/59.94P, 50P, 59.94i, 50i, 29.97P, 23.98P, 25P
XAVC-L 25 mode: 1920×1080/59.94i, 50i

MPEG HD422 mode: 1920×1080/59.94i, 50i, 29.97P, 23.98P, 25P 1280×720/59.94P, 50P, 29.97P, 23.98P, 25P

Recording/Playback Time
XAVC-I mode 4K/QFHD 59.94P
When using QD-G128A (128GB): Approx. 22 minutes,
When using QD-G64A (64GB): Approx. 11 minutes
XAVC-I mode 4K/QFHD 50P
When using QD-G128A (128GB): Approx. 26 minutes,
When using QD-G64A (64GB): Approx. 13 minutes
XAVC-I mode 4K/QFHD 29.97P
When using QD-G128A (128GB): Approx. 44 minutes,
When using QD-G64A (64GB): Approx. 22 minutes
PXW-FS7
Recording/Playback Time XAVC-I mode 4K/QFHD 23.98P
When using QD-G128A (128GB): Approx. 55 minutes,
When using QD-G64A (64GB): Approx. 27 minutes
XAVC-I mode 4K/QFHD 25P
When using QD-G128A (128GB): Approx. 52 minutes,
When using QD-G64A (64GB): Approx. 26 minutes
Recording/Playback Time
ProRes 422 HQ*2
“ProRes 422 HQ
59.94i/29.97P mode
When using QD-G128A (128GB): Approx. 60 minutes,
When using QD-G64A (64GB): Approx. 30 minutes”
“ProRes 422 HQ
50i/25P mode
When using QD-G128A (128GB): Approx. 72 minutes,
When using QD-G64A (64GB): Approx. 36 minutes
ProRes 422 HQ
23.98P mode
When using QD-G128A (128GB): Approx. 74 minutes
When using QD-G64A (64GB): Approx. 37 minutes
Recording/Playback Time
ProRes 422 HQ*2
ProRes 422
59.94i/29.97P mode
When using QD-G128A (128GB): Approx. 90 minutes
When using QD-G64A (64GB): Approx. 45 minutes
ProRes 422
50i/25P mode
When using QD-G128A (128GB): Approx. 108 minutes
When using QD-G64A (64GB): Approx. 54 minutes
ProRes 422
23.98P mode
When using QD-G128A (128GB): Approx. 112 minutes
When using QD-G64A (64GB): Approx. 56 minutes
Lens
Filter Diameter
95 mm
Focal Length
28mm to 135mm
Focus
Internal
Iris
Nine blades (circular perture) F/4 to F/22 (click or click-less)
Lens Mount
Sony E-Mount
Zoom Ratio
4.8x
Note
SEL-28135G 28-135mm lens is supplied as standard with PXW-FS7K model. PXW-FS7 model is supplied without lens.
Camera Section
Imaging Device (Type)
Super35 type Single-chip Exmor CMOS
Effective Picture Elements
17:9 4096 (H) x 2160 (V)
16:9 3840 (H) x 2160 (V)
Built-in Optical Filters
Clear, 1/4ND, 1/16ND, 1/64ND
Sensitivity (2000 lx, 89.9% reflectance)
Video Gamma: T14 (3840 x 2160/23.98P mode 3200K)
ISO Sensitivity
ISO 2000(S-Log3 Gamma D55 Light source)
Minimum Illumination
0.7 lx (+18dB,23.98P,Shutter OFF,ND Clear, F1.4)
S/N Ratio
57 dB (Y) (typical)
Shutter Speed
1/3 sec to 1/9,000 sec
Slow & Quick Motion Function
XAVC-I mode 3840×2160: 1 to 60 frames (59.94P, 50P, 29.97P, 23.98P, 25P)
XAVC-I mode 1920×1080: 1 to 180 frames (59.94P, 29.97P, 23.98P)1 to 150 frames (50P,25P)
XAVC-L mode 3840×2160：1 to 60 frames (59.94P, 50P, 29.97P, 23.98P, 25P)
XAVC-L mode 1920×1080: 1 to 120 frames (59.94P, 50P, 29.97P, 23.98P, 25P)
White Balance
Preset, Memory A, Memory B(1500K-50000K)/ATW
Gain
-3, 0, 3, 6, 9, 12, 18 dB, AGC
Gamma Curve
STD,HG,User,S-log3
Input/Output
Audio Input
XLR-type 3-pin (female) (x2), line/mic/mic +48 V selectable Mic Reference: -40, -50, -60dBu
SDI Output
BNC(x2), switchable with 3G-SDI/HD-SDI
SMTPE292M/424M/425M
USB
USB device, mini-B (x1)
Headphone Output
Stereo mini jack (x1) -16dBu 16Ω
Speaker Output
Monaural
DC Input
DC jack
Remote
Stereo mini-minijack (Φ2.5 mm)
HDMI Output
Type A (x1)
Option
4-pin, Type A for W-LAN (x1)
Monitoring
Built-in LCD Monitor
8.8cm (3.5 type) Approx. 1.56M dots
Built-in Microphone
Built-in Microphone
Omni-directional monoral electret condenser microphone.
Media
Type
XQD Card slot(x2)
SD Card slot(x1) for saving configuration data
In the Box
  • Boyd Cap (1)
  • Viewfinder (1)
  • Eyepiece (1)
  • Grip Remote Control (1)
  • USB wireless LAN module IFU-WLM3 (1)
  • Wireless remote commander (1) (RMT-845)
  • WA Adaptor Bracket (1)
  • MPA-AC1 AC Adapter (1)
  • BC-U1 battery charger (1)
  • BP-U30 battery pack (1)
  • Power cord (2)
  • USB cable (1)
  • Operating Guide (2)
  • CD-ROM "Manuales for Solid-State Memory Camcorder" (1)
