General |
Mass |
Approx. 2.0 kg (body only)
Approx. 4.5 kg (with Viewfinder, Eyepiece, Grip Remote Control, BP-U30 battery, SELP18110G LENS without tripod mount, an XQD memory card) |
Dimensions (W x H x D) *1 |
158.9 x 245.2 x 247mm (body without protrusions) |
Power Requirements |
DC 16.5V (battery pack)
DC 12.0V (AC adaptor) |
Power Consumption |
Approx. 19W (while recording XAVC-I QFHD 59.94P, SELP18110G Lens, Viewfinder ON, not using external device) |
Operating Temperature |
0°C to 40°C
32°F to 104°F |
Storage Temperature |
-20°C to +60°C
-4°F to +140°F |
Battery Operating Time |
Approx. 1 hrs. with BP-U30 battery (while recording XAVC-I QFHD 59.94P, SELP18110G Lens, Viewfinder ON, not using external device)
Approx. 2 hrs. with BP-U60 battery while recording XAVC-I QFHD 59.94P, SELP18110G Lens, Viewfinder ON, not using external device)
Approx. 3 hrs. with BP-U90 battery (while recording XAVC-I QFHD 59.94P, SELP18110G Lens, Viewfinder ON, not using external device) |
 Recording Format (Video) |
XAVC-I mode:DCI4K 59.94P CBG, bit rate 600Mbps, MPEG-4 H.264/AVC
XAVC-I mode:DCI4K 50P CBG, bit rate 500Mbps, MPEG-4 H.264/AVC
XAVC-I mode:DCI4K 29.97P CBG, bit rate 300Mbps, MPEG-4 H.264/AVC
XAVC-I mode:DCI4K 23.98P CBG, bit rate 240Mbps, MPEG-4 H.264/AVC
XAVC-I mode:DCI4K 24.00P CBG, bit rate 240Mbps, MPEG-4 H.264/AVC
XAVC-I mode:DCI4K 25P CBG, bit rate 250Mbps, MPEG-4 H.264/AVC
XAVC-I mode:QFHD 59.94P CBG, bit rate 600Mbps, MPEG-4 H.264/AVC
XAVC-I mode:QFHD 50P CBG, bit rate 500Mbps, MPEG-4 H.264/AVC
XAVC-I mode:QFHD 29.97P CBG, bit rate 300Mbps, MPEG-4 H.264/AVC
XAVC-I mode:QFHD 23.98P CBG, bit rate 240Mbps, MPEG-4 H.264/AVC |
Recording Format (Video) |
XAVC-I mode:QFHD 25P CBG, bit rate 250Mbps, MPEG-4 H.264/AVC
XAVC-I mode:HD 59.94P VBR, maximum bit rate 222Mbps, MPEG-4 H.264/AVC
XAVC-I mode:HD 50P VBR, maximum bit rate 185Mbps, MPEG-4 H.264/AVC
XAVC-I mode:HD 59.94i VBR, maximum bit rate 111Mbps, MPEG-4 H.264/AVC
XAVC-I mode:HD 50i VBR, maximum bit rate 112Mbps, MPEG-4 H.264/AVC
XAVC-I mode:HD 29.97P VBR, maximum bit rate 111Mbps, MPEG-4 H.264/AVC
XAVC-I mode:HD 23.98P VBR, maximum bit rate 89Mbps, MPEG-4 H.264/AVC
XAVC-I mode:HD 25P VBR, maximum bit rate 112Mbps, MPEG-4 H.264/AVC
XAVC-L QFHD 59.94P/50P mode: VBR, maximum bit rate 150Mbps, MPEG-4 H.264/AVC |
Recording Format (Video) |
XAVC-L QFHD 29.97P/23.98P/25P mode: VBR, maximum bit rate 100Mbps, MPEG-4 H.264/AVC
XAVC-L HD 50 mode: VBR, maximum bit rate 50Mbps, MPEG-4 H.264/AVC
XAVC-L HD 35 mode:VBR, maximum bit rate 35Mbps, MPEG-4 H.264/AVC
XAVC-L HD 25 mode:VBR, maximum bit rate 25Mbps, MPEG-4 H.264/AVCMPEG HD422 mode:CBR, maximum bit rate 50Mbps, MPEG-2 422P@HL |
Recording Format (Audio) |
LPCM 24 bits, 48 kHz, 4 channels |
Recording Frame Rate |
XAVC-I DCI4K mode: 4096×2160/ 59.94P, 50P, 29.97P, 23.98P, 24P, 25P
XAVC-I QFHD mode: 3840×2160/ 59.94P, 50P, 29.97P, 23.98P, 25P
XAVC-I HD mode: 1920×1080/59.94P, 50P, 59.94i, 50i, 29.97P, 23.98P, 25P
XAVC-L QFHD mode: 3840×2160/59.94P, 50P, 29.97P, 23.98P, 25P
XAVC-L HD 50 mode: 1920×1080/59.94P, 50P, 59.94i, 50i, 29.97P, 23.98P, 25P
XAVC-L 35 mode: 1920×1080/59.94P, 50P, 59.94i, 50i, 29.97P, 23.98P, 25P
XAVC-L 25 mode: 1920×1080/59.94i, 50i
MPEG HD422 mode: 1920×1080/59.94i, 50i, 29.97P, 23.98P, 25P
1280×720/59.94P, 50P, 29.97P, 23.98P, 25P |
Recording/Playback Time |
XAVC-I mode QFHD 59.94P
When using QD-G128A(128GB):
Approx. 22 minutes
XAVC-I mode QFHD 50P
When using QD-G128A(128GB):
Approx. 26 minutes
XAVC-I mode QFHD 29.97P
When using QD-G128A(128GB):
Approx. 44 minutes
XAVC-I mode QFHD 23.98P
When using QD-G128A(128GB):
Approx. 55 minutes
XAVC-I mode QFHD 25P
When using QD-G128A(128GB):
Approx. 52 minutes |
Recording/Playback Time |
XAVC-I mode HD 59.94P
When using QD-G128A(128GB):
Approx. 59 minutes
XAVC-I mode HD 50P
When using QD-G128A(128GB):
Approx. 71 minutes
XAVC-I mode HD 59.94i
When using QD-G128A(128GB):
Approx. 118 minutes
XAVC-I mode HD 50i
When using QD-G128A(128GB):
Approx. 141 minutes
XAVC-I mode HD 29.97P
When using QD-G128A(128GB):
Approx. 118 minutes |
Recording/Playback Time |
XAVC-I mode HD 23.98P
When using QD-G128A(128GB):
Approx. 147 minutes
XAVC-I mode HD 25P
When using QD-G128A(128GB):
Approx. 141 minutes
XAVC-L mode QFHD 59.94P/50P
When using QD-G128A(128GB):
Approx. 87 minutes
XAVC-L mode QFHD 29.97P/23.98P/25P mode:
When using QD-G128A(128GB):
Approx. 131 minutes
XAVC-L 50 mode
When using QD-G128A(128GB):
Approx. 262 minutes |
Recording/Playback Time |
XAVC-L 35 mode
When using QD-G128A(128GB):
Approx. 374 minutes
XAVC-L 25 mode
When using QD-G128A(128GB):
Approx. 524 minutes
MPEG HD422 mode
When using QD-G128A(128GB):
Approx. 262 minutes |
Lens |
Lens Mount |
E-mount (lever lock type) |
Camera Section |
Imaging Device (Type) |
Super35 type Single-chip Exmor CMOS |
Effective Picture Elements |
17:9 4096 (H) x 2160 (V)
16:9 3840 (H) x 2160 (V) |
Built-in Optical Filters |
ND filters
OFF: CLEAR
1: 1/4ND
2: 1/16ND
3: 1/64ND
Linear variable ND (1/4ND to 1/128ND) |
Sensitivity (2000 lx, 89.9% reflectance) |
Video Gamma: T14 (3840 x 2160/23.98P mode 3200K) |
ISO Sensitivity |
ISO 2000(S-Log3 Gamma D55 Light source) |
Minimum Illumination |
0.7 lx (+18dB,23.98P,Shutter OFF,ND Clear, F1.4) |
S/N Ratio |
57 dB (Y) (typical) |
Shutter Speed |
1/3 sec to 1/9,000 sec |
Slow & Quick Motion Function |
XAVC-I mode 3840×2160: 1 to 60 frames (59.94P, 50P, 29.97P, 23.98P, 25P)
XAVC-I mode 1920×1080:1 to 180 frames (59.94P, 29.97P, 23.98P) 1 to 150 frames (50P,25P)
XAVC-L mode 3840×2160?1 to 60 frames (59.94P, 50P, 29.97P, 23.98P, 25P)
XAVC-L mode 1920×1080: 1 to 120 frames (59.94P, 50P, 29.97P, 23.98P, 25P) |
White Balance |
Preset, Memory A, Memory B(1500K-50000K)/ATW |
Gain |
-3, 0, 3, 6, 9, 12, 18 dB, AGC |
Gamma Curve |
STD,HG,User,S-Log2, S-Log3 |
Input/Output |
Audio Input |
XLR-type 3-pin (female) (x2), line/mic/mic +48 V selectable Mic Reference: -40, -50, -60dBu |
SDI Output |
BNC(x2), switchable with 3G-SDI/HD-SDI SMTPE292M/424M/425M |
USB |
USB device, mini-B (x1) |
Headphone Output |
Stereo mini jack (x1) -16dBu 16Ω |
Speaker Output |
Monaural |
DC Input |
DC jack |
Remote |
Stereo mini-mini jack (Φ2.5 mm) |
HDMI Output |
Type A (x1) |
Option |
4-pin, Type A for W-LAN (x1) |
Monitoring |
Built-in LCD Monitor |
8.8cm (3.5 type) Approx. 1.56M dots |
Built-in Microphone |
Built-in Microphone |
Omni-directional monaural electret condenser microphone |
Media |
Type |
XQD Card slot(x2)
SD Card slot(x1) for saving configuration data |
Notes
*1 The values for dimensions are approximate.
*2 Viewable area measured diagonally.
*3 ECS: Extended Clear Scan |
