Yamaha CZR15 800W 2-Way 15″ Passive Loudspeaker
Yamaha CZR15 is a 2-way loudspeaker offering high power handling and outstanding sonic performance in a portable, lightweight, yet rugged design. Its versatile, compact enclosure design makes the lightweight CZR15 ideal for a range of live performances and installed sound environments?from live bands at outdoor festivals to DJ?s in clubs?these loudspeakers deliver crystal clear, high-quality sound with impressive low-frequency performance.
CZR Series loudspeakers come equipped with plenty of rigging points for any installation environment, allowing for rigged application with standard eyebolts. Specialized U brackets are also available for convenient flying/hanging installation. Eyebolts are not included.
Features:
- 2-way loudspeaker with a 2? HF and a 15″ LF
- Features Yamaha’s own Wide Dispersion CD Waveguide Horn
- High power 800W(PGM) power handling and Bi-amp capable
- The floor monitoring setting enables mirroring configuration
- Lightweight yet very durable plywood cabinet with premium graded Polyurea coating
- Dual-angle pole socket
- Optional speaker cover (SPCVR-DZR15)
- Rotatable horn and a variety of U-bracket options (UB-DZR15H/V) for rigging allow for very flexible setup and speaker placement
- Durable Black or white finish
To view more Yamaha Products
CBR Series Related Products:
- Yamaha CBR10 10? Passive Loudspeaker
- Yamaha CBR12 12? Passive Loudspeaker
- Yamaha CBR15 15? Passive Loudspeaker
CHR Series Products:
- Yamaha CHR10 10? Passive Loudspeaker
- Yamaha CHR12M 12? Passive Loudspeaker
- Yamaha CHR15 15? Passive Loudspeaker
CXS series:
CZR Series Products:
- Yamaha CZR10 10?Passive Loudspeaker
- Yamaha CZR12 12? Passive Loudspeaker
- Yamaha DZR315-D Powered Loudspeaker
VKE Series Products:
- Yamaha VKE2010 10? LF Loudspeaker
- Yamaha VKE2012 12? LF Loudspeaker
- Yamaha VKE2015 15? LF Loudspeaker
VS series Products:
VXS Series Products:
Specifications
Click to rate this post!
[Total: 1 Average: 5]
| Speaker type | 2-way Speaker, Bass-reflex | |
|---|---|---|
| Frequency range (-10dB) | Passive: 43 Hz – 20 kHz, Normal (1): 34 Hz – 20 kHz, FOH (1): 33 Hz – 20 kHz | |
| Coverage area | H90ﾟ x V50ﾟ Rotatable Constant Directivity Horn | |
| Floor Monitor Angle | 50° Symmetrical | |
| Components | LF | 15″ Cone, 3″ Voice Coil, Neodymium magnet |
| HF | 2″ Voice Coil, 1″ Throat Compression Driver, Titanium diaphragm, Neodymium magnet | |
| Crossover | 2.0 kHz | |
| Power rating | NOISE | Passive (EIA 426-A) 400 W, Bi-amp LF (EIA 426-A): 400W, HF (AES): 50W |
| PGM | Passive (EIA 426-A) 800 W, Bi-amp LF (EIA 426-A): 800W, HF (AES): 100W | |
| PEAK | Passive (EIA 426-A) 1600 W, Bi-amp LF (EIA 426-A): 1600W, HF (AES): 200W | |
| Nominal impedance | Passive: 8Ω, Bi-amp: LF: 8Ω, HF: 16Ω | |
| SPL | Sensitivity (1W; 1m on-axis) | Passive: 97dB SPL, Bi-amp: LF: 99dB SPL, HF: 108dB SPL |
| Peak (Calculated) | Passive: 129 dB SPL, Bi-amp: LF: 131dB SPL, HF: 131dB SPL | |
| I/O connectors | SpeakON NL4MP x 2 (Parallel) | |
| Handle | Aluminium die-cast, Side x2 | |
| Pole socket | Φ35 mm x2 (0° or -7°) | |
| Rigging | M10 x 12 | |
| Dimensions | W | 450 mm (17.7″) |
| H | 761 mm (30.0″) (with rubber feet) | |
| D | 460 mm (18.1″) | |
| Net weight | 21.3 kg (47.0 lbs) | |
| Options | Bracket: UB-DZR15H/V, Cover: SPCVR-DZR15 | |
| Others | Enclosure Material, Finish, Color: Plywood, Durable Polyurea coating, Black/White | |
- 1: With recommended DSP processing.
2: Half space (2Ï€)
