Yamaha MG06X 6-Channel Mixing Console
SGD 209.61 excl. Tax
Key Features:
- 6-Channel Mixing Console
- Max. 2 Mic / 6 Line Inputs (2 mono + 2 stereo)
- 1 Stereo Bus
- High-grade effects: SPX with 6 programs
- XLR balanced outputs
- PAD switch on mono inputs
- +48V phantom power
| Weight | 4 kg |
|---|
Description
Click to rate this post!
[Total: 6 Average: 5]
Yamaha MG06X 6-Inputs Mixing Console with Built-in Effects
Yamaha MG06X is a 6-Channel Mixing Console: Max. 2 Mic / 6 Line Inputs (2 mono + 2 stereo) / 1 Stereo Bus. suitable for a diverse range of users and applications. For installed, recording, or live music settings, the solid construction and flexible design of these consoles let you shape your sound with confidence, continually delivering peak performance and a level of sound quality and reliability unrivaled in its class. With phantom power, MG Series consoles allow you to take full advantage of the greater frequency response and high sound quality of condenser microphones. A high-pass filter allows you to eliminate unwanted low-frequency noise, for a smoother, cleaner mix.
Discrete Class-A Mic Preamps
Everything you do as a sound engineer is dependent on the quality of your preamps, which determines the direction your mix will take, and ultimately how good it is going to sound. MG Series mixing consoles feature Yamaha’s studio-grade discrete class-A D-PRE preamps, which utilize an inverted Darlington circuit comprising two cascading transistors in a configuration that provides more power with lower impedance.
High Quality Sound OP-AMP
The head amp determines sound quality, and op-amp integrated circuits are one of the most important parts in the head amp circuit.
Switchable Phantom pwer & Pad Switch
With phantom power, MG Series consoles allow you to take full advantage of the greater frequency response and high sound quality of condenser microphones.
1-Knob Compressors
Originally a Yamaha innovation, 1-knob compressors are now an industry standard that gives you instant access to optimized compression settings via a single rotary control.
EQ and high-pass filters
The MG Series benefits from Yamaha’s unparalleled experience in designing pro audio gear, featuring 3-band equalizers on all mono channels for precise control of your sound. High-pass filter allows you to eliminate unwanted low-frequency noise, for a smoother, cleaner mix.
* MG06 / 06X feature 2-band equalizers on all mono channels.
To view more Yamaha Products
Other site:
Digital Mixer Related Products:
- Yamaha TF-RACK Digital Mixer
- Yamaha CL1 Digital Mixing Console
- Yamaha CL3 Digital Mixing Console
- Yamaha CL5 Digital Mixing Console
- Yamaha QL1 Digital Mixing Console
- Yamaha QL5 Digital Mixing Console
- Yamaha TF1 Digital Mixing Console
- Yamaha TF3 Digital Mixing Console
- Yamaha TF5 Digital Mixing Console
- Yamaha MG10X Mixing Console
- Yamaha MG10XU Mixing Console
- Yamaha EMX5014C Powered Mixer
SKR-CC18OCT2024
Specifications
Click to rate this post!
[Total: 6 Average: 5]
| MG06X | ||
|---|---|---|
| Mixing capability | On-board processors | SPX algorithm: 6 programs |
| I/O | Phantom power | +48 V |
| Digital I/O | – | |
| Input Channels | Mono[MIC/LINE] | 2 |
| Mono/Stereo[MIC/LINE] | – | |
| Stereo[LINE] | 2 | |
| Output Channels | STEREO OUT | 2 |
| MONITOR OUT | – | |
| PHONES | 1 | |
| AUX SEND | – | |
| GROUP OUT | – | |
| Bus | Stereo: 1 | |
| Input Channel Function | PAD | 26 dB (Mono) |
| HPF | 80 Hz, 12 dB/Oct (Mono) | |
| COMP | – | |
| EQ HIGH | (Mono) Gain: +15 dB/-15 dB, Frequency: 10 kHz shelving | |
| EQ MID | – | |
| EQ LOW | (Mono) Gain: +15 dB/-15 dB, Frequency: 100 Hz shelving | |
| PEAK LED | LED turns on when post EQ signal reaches 3 dB below clipping | |
| Level Meter | 2 x 7 -segment LED meter [PEAK, +6, +3, 0, -3, -10, -20 dB] | |
| Total harmonic distortion | 0.01 % @ +8dBu (20 Hz to 20kHz), GAIN knob: Min, 0.003 % @ +18dBu (1kHz), GAIN knob: Min | |
| Frequency response | +0.5 dB/-0.5 dB (20 Hz to 20 kHz) , refer to the nominal output level @ 1 kHz, GAIN knob: Min | |
| Hum & noise level | Equivalent input noise | -128 dBu (Mono Input Channel, Rs: 150Ω, GAIN knob: Max) |
| Residual output noise | -102 dBu (STEREO OUT, STEREO LEVEL knob: Min) | |
| Crosstalk | -88 dB | |
| Power requirements | PA-130 (DC12 V/1.0 A, Cable length = 1.8 m), 120 V, 60 Hz, MU18 (DC12 V/1.5 A, Cable length = 1.5 m), 100 V-240 V, 50 Hz/60 Hz or equivalent recommended by Yamaha | |
| Power consumption | 12 W | |
| Dimensions | W | 149 mm (5.9″) |
| H | 62 mm (2.4″) | |
| D | 202 mm (7.9″) | |
| Net weight | 0.9 kg (1.98 lbs.) | |
| Accessories | Included Accessory: AC Adaptor, Owner’s Manual, Technical Specifications, Optional Accessory: Mic Stand Adaptor BMS-10A | |
| Others | Operating Temperature: 0 to +40ËšC | |
- 0 dBu = 0.775 Vrms Output impedance of signal generator (Rs) = 150Ω
- All level controls are nominal if not specified.
- Hum & noise level: Noise is measured with an A-weighting filter.
- Crosstalk： Measured with 1 kHz band pass filter.
In The Box
Click to rate this post!
[Total: 6 Average: 5]
- MG06X Mixing Console
- AC Adaptor
- Owner’s Manual
- Technical Specifications
