Audio-Technica ATDM-1012 Digital SmartMixer

Audio-Technica ATDM-1012 Digital SmartMixer

Audio-Technica ATDM-1012 Digital SmartMixer is a flexible and easy-to-use solution for a wide variety of installed audio applications where the mix-minus operation or audio pickup from specific zones within a space is required. Its powerful feature set makes it ideal for hospitality, corporate or demanding courtroom settings, and many more.

The ATDM-1012 is a 14-input / 12-bus matrix mixer featuring 10 mic/line inputs with high-quality preamps, two stereo line inputs, USB audio I/O, eight balanced outputs, and two unbalanced stereo outputs. Ten additional digital inputs can be added either via an AT-LINK digital connection or over Dante – available with the Dante-enabled ATDM-1012DAN version.

Each input channel is equipped with phase inversion, a low-cut filter, and a four-band parametric EQ. Inputs can be routed through the routing matrix to any of the 12 busses, which each feature independent volume settings. The ATDM-1012’s smart mixing capabilities offer four mixing groups that can either be gain-sharing or gating mixers. Additionally, ten Acoustic Echo Cancellation (AEC) processors, ten compressors/de-users, and eight feedback suppressors can be freely assigned to any of the input or output channels to ensure maximum audio quality at all times.

The ATDM-1012’s versatile, highly configurable nature is complemented by its ease of operation; audio input/output settings can be made from the front panel, with full control achieved via the Web Remote Manager software application. In addition, the mixer can be accessed remotely over IP via a web browser, adding further flexibility.

Features for ATDM-1012

• Equipped with 22 Inputs × 12 Buses full matrix mixer, including 8 Sub Inputs systems
• 10 MIC/LINE inputs with high-quality microphone preamplifier and stereo amplifier (CH 7/8, 9/10 can be used as Stereo Link)
• Up to two sets of ES954 Hanging Array Microphones (sold separately) can be connected to the microphone inputs
• 8 Balanced outputs with BTL circuit
• 2 Unbalanced stereo outputs and Microphone level output
• USB audio input/output (1 stereo input, 1 stereo output)
• Independent 4 Groups of SmartMixer with optional gain sharing or gating mode
• Equipped with echo canceller (up to 10 Microphone inputs) and noise canceller which can be used at the same time
• Each input system is equipped with a 4-band equalizer (sub-input only low-cut) and each output system is a 12-band equalizer
• Equipped with 10 Compressors/DeEsser and 8 frequency band Feedback Suppressors which can be inserted into each input/output system
• 2 Unbalanced stereo inputs with Ducker function
• Each output system has a Limiter
• Equipped with a convenient Oscillator function, you can check the audio of each output system
• Audio input/output settings can be made from the front panel and detailed settings can be made from the PC by Web Remote
• Offline device settings can be done through the Web Remote Manager application
• Can be controlled from the outside through the IP remote protocol
