Datavideo HDR-60 HD/SD Digital Video Recorder
USD 2,086.00 excl. Tax
Product Highlights:
- Hard drive based portable video recorder
- Supports multiple input and output configurations
- Convenient for post-production or play out
- Various built-in functions
- Timelapse Recording
- Accidental Power-Off Protection
| Weight | 2.5 kg |
|---|
This product has been discontinued.
Description
Click to rate this post!
[Total: 0 Average: 0]
Datavideo HDR-60 HD/SD Digital Video Recorder
Hard drive based portable video recorder
The HDR-60 is a portable video recorder with removable hard drive enclosure, designed for studio desktop applications.
Supports multiple input and output configurations
1 x HD/SD-SDI input, output and loop through with embedded audio; 1 x HDMI output with embedded audio.
Convenient for post-production or play out
Record with MPEG-2 4:2:2 NTFS file system in MOV or MXF formats on SSD drives up to 125Mbps.
Various built-in functions
Genlock, black burst and time code supported
Features:
- NTFS – HDR-60 uses the NTFS file system.
- On the Fly – Media files are made on the fly with the HDR-60.
- Time Code – HDR-60 has time code input and output.
- Gen-Lock – HDR-60 features gen-lock input and pass-through.
- Locking Power Connector – Locking connectors keep the power plug securely attached.
- Power-On Features – HDR-60 has Power-On Record and Power-On Play.
- Timelapse Recording – HDR-60 is able to do timelapse recording.
- 1080p Recording – HDR-60 can record in 1080p, as well as 1080i, 720p, 576i, and 480i.
- Accidental Power-Off Protection – In the case of an accidental power-off, like a blackout, the recorded file will still be saved, minus 2 seconds at the end of the file.
- Ref-In – HDR-60 has Ref-in/loop-through, Black Burst, and Tri-level Signal.
Specifications
Click to rate this post!
[Total: 0 Average: 0]
| Video Standard | HD & SD |
| Video Format | 1080p 23.97/24Hz 1080i 50/59.94/60Hz 720p 50/59.94/60Hz 576i 50Hz, 480i 59.94Hz |
| Supported Video Input Signal | 1x SDI |
| Monitoring / Playback Output | 1x SDI (Input Loop Thru) 1x HDMI, 1x SDI (Out) |
| Analog Audio Input / Output | 2x Balanced mini XLR (Stereo pair) |
| Embedded Audio | Both In & Out (8-CH on SDI/HDMI) |
| Storage Medium | 2.5″ Hard Drive / SSD*, Max capacity 1TB |
| Estimated Record Time (min per 10GB) | SD: 19 (50Mbps) ~ 70 (8Mbps) HD: 8 (125Mbps) ~ 62 (10Mbps) |
| Recording Media | Removable Hard Drive / SSD, transfer data via USB2.0 |
| Storage File System | NTFS |
| Recorded File Format | MXF OP1A, MOV |
| Video Recording Bit Rate / Color Sampling | MPEG2 Long GOP HD: 1. 10Mbps 4:2:0 1440×1080/1280×720, 2. 25Mbps 4:2:0 1440×1080/1280×720, 3. 35Mbps 4:2:2 1920×1080/1280×720, 4. 50Mbps 4:2:2 1920×1080/1280×720, 5. 65Mbps 4:2:2 1920×1080/1280×720, 6. 120Mbps 4:2:2 1920×1080/1280×720, MPEG2 Long GOP SD 1. 8Mbps 4:2:0 720×480/720×576 2. 15Mbps 4:2:2 720×480/720×576 3. 30Mbps 4:2:2 720×480/720×576 4. 50Mbps 4:2:2 720×480/720×576 MPEG2 I-Frame Only HD 1. 80Mbps 4:2:2 1920×1080/128 |
| Audio Recording Format | Uncompressed PCM Sampling rate 48KHz 24bit |
| Time Code In / Out | Yes |
| External Sync / Genlock | Black Burst & Tri-level with loop thru |
| Power Failure Protection | Content saved up to last second before power failure |
| Chassis | Desktop |
| Dimensions (LxWxH) | 210 x 254 x 96 mm |
| Weight | 2.7 kg |
| Operating Temp. Range | 0~40 °C |
| Power | DC 12V, 2A |
In The Box
Click to rate this post!
[Total: 0 Average: 0]
- 1x HDR-60 product
- 1x AD Switch DC 12V
- 1x USB Cable (Y type)
- 2x Mini XLR F to M XLR cable
- 2x Mini XLR F to F XLR cable
- 2x 2.5″ Removable HDD Enclosure
- 10x M3 X 4 m/m Screws
- 2x 2.0 X 6 m/m Screws
- 2x HD Label
- 4x Label
- 1x Thank You Card
