Panasonic PT-VMZ51S 5,200 Lumen LCD Laser Projector
Product Highlights:
- Compact and lightweight LCD laser projector
- Clear Images That Are Easy to See in Bright Rooms
- Installation Flexibility Adapts Projection to Any Space
- Smooth and Effortless Collaboration
Description
Panasonic PT-VMZ51S WUXGA Laser Projector with 5,200 Lumens
The Panasonic PT-VMZ51S is a compact, high-brightness laser projector—perfect for classrooms, meeting rooms, performance venues, and even golf simulators. Measuring just 6.5 kg and featuring a portable design, this projector delivers impactful visuals without taking up your entire ceiling rig.
PT-VMZ51S Projector Key Features:
Brilliant Laser Lighting
- 5,200 ANSI lumens of brightness ensure vivid, crisp images—even in fully lit spaces.
- Long-lasting laser-phosphor light source, rated at up to 20,000 hours in Normal mode and 24,000 hours in Eco mode, eliminates frequent lamp replacements.
Sharp, High-Definition Picture
- Native WUXGA resolution (1920×1200) for crisp display of presentations, spreadsheets, graphs, and HD videos.
- Dynamic contrast ratio of 3,000,000:1, powered by frame-by-frame brightness adjustment, delivers deeper blacks and vivid colors.
Flexible Installation
- Short throw lens (1.09–1.77:1 optical zoom, extendable to 2.21:1) makes it ideal for tight rooms or large displays from close range.
- Vertical lens shift (+44%) and horizontal shift (±20%), plus vertical keystone (±25°) and horizontal keystone (±35°), for easy image alignment, even at an angle.
- Supports 360° and rear projection, ceiling/floor mount options, and corner adjustment for installation in unconventional setups.
Comprehensive Connectivity
- Two HDMI ports (supporting 4K/30p input), dual VGA, USB-A (power), LAN/Digital Link, and RS-232 control offer robust connectivity.
- (Optional) Wireless projection capability via add-on module, plus support for Panasonic’s “Daylight View” which automatically optimizes image clarity in well-lit settings.
Quiet & Reliable Operation
- Produces about 36 dB in Normal mode and 26–27 dB in Quiet/Eco mode—quiet enough for distraction-free meetings or classrooms.
- Energy-efficient with 300 W max power draw and only 0.5 W standby, saving operating costs.
- Durable, washable filter rated for 10k–20k hours, depending on the environment.
Ideal Use Scenarios
- Educational environments & corporate spaces: excellent image quality under classroom/office lighting.
- Golf simulators & training centers: short-throw lens and lens shift make it easy to avoid shadows, per user feedback.
- Portable AV setups: lightweight form factor and multiple mounting options support quick setup and tear-down.
Why Choose Panasonic PT-VMZ51S Projector?
- Exceptional brightness and contrast: ideal for daylight viewing
- Laser longevity with low maintenance: cuts operating costs
- Compact, light, and installation‑ready: adapt easily to any space
- Full professional control and connectivity: seamless integration
- Eco‑conscious design: sustainable and energy-efficient
The Panasonic PT‑VMZ51S strikes a balance of powerful brightness, sharp image quality, and installation flexibility, all in a portable, robust package. Whether it’s for classroom, corporate, or simulator use, it’s a top-tier laser projector engineered for efficiency and visual impact.
To view more Panasonic Products
View more LCD and Laser Projectors
Projector Types
Specifications
| Projector type | LCD projectors |
| Display method | Transparent LCD panel (x 3, R/G/B) |
| Display Device -> Panel size | 16.3 mm (0.64 in) diagonal (16:10 aspect ratio) |
| Display Device -> Drive method | Active-matrix method |
| Display Device -> Number of pixels | 2,304,000 (1920 x 1200) pixels |
| Light source | Laser diodes |
| Light output | 5,200 lm |
| Light output (ANSI) | 5,200 lm |
| Time until light output declines to 50 % -> NORMAL | 20,000 hours [NORMAL] |
| Time until light output declines to 50 % -> ECO | 24,000 hours [ECO] |
| Time until light output declines to 50 % -> QUIET | 20,000 hours [QUIET] |
| Resolution | WUXGA (1920 x 1200 pixels) |
| Contrast Ratio (typ.) | 3,000,000:1 (Full On/Full Off)(When [PICTURE MODE] is set to [DYNAMIC] and [DYNAMIC CONTRAST] is set to [1].) |
| Screen size (diagonal) | 0.76–7.62 m (30–300 in), 16:10 aspect ratio |
| Center-to-corner zone ratio | 85% |
| Lens | 1.6x manual zoom (throw ratio: 1.09–1.77:1), manual focus lens, F 1.60–2.12, f 15.30–24.64 mm |
| Digital Zoom Extender | Throw Ratio 1.09–2.21:1 (Corresponding value. When used together with optical zoom.) |
| Lens shift -> Vertical(from center of screen) | 44% |
| Lens shift -> Horizontal(from center of screen) | ±20 % |
| Keystone correction range | Vertical: ±25 °, Horizontal: ±35 ° |
| Installation | Ceiling/floor, front/rear, free 360-degree installation |
| Terminals -> HDMI IN | HDMI 19-pin x 2 (Compatible with HDCP, Deep Color, 4K/30p signal input), CEC supported |
| Terminals -> COMPUTER IN（D-SUB 15pin） | D-sub 15-pin (female) x 2 (RGB/YPBPR/YCBCR) |
| Terminals -> AUDIO IN(M3 Stereo Mini Jack) | M3 stereo mini-jack x 2 |
| Terminals -> AUDIO OUT(M3 Stereo Mini Jack) | M3 stereo mini-jack x 1 |
| Terminals -> SERIAL IN | D-sub 9-pin (female) x 1 for computer control (RS-232C compliant) |
| Terminals -> DIGITAL LINK IN / LAN | — |
| Terminals -> LAN | RJ-45 x 1 for network control, 10Base-T, 100Base-TX, compatible with PJLink [Class 2] |
| Terminals -> USB TYPE A | USB connector (Type A) x 1 for Memory Viewer function, optional AJ-WM50 Series Wireless Module,power supply (DC 5 V, maximum 2 A) |
| Protocol versions | IPv4, IPv6 |
| Power supply | AC 100 V–240 V, 50/60 Hz |
| Maximum power consumption | 300 W (3.1–1.3 A) (305 VA)(Power consumption is 290 W at 200–240 V) |
| On-mode power consumption(Operating mode) -> Normal | [NORMAL] |
| 265 W (100–120 V), | |
| 255 W (200–240 V) | |
| On-mode power consumption(Operating mode) -> Eco | [ECO] |
| 190 W (100–120 V), | |
| 180 W (200–240 V) | |
| On-mode power consumption(Operating mode) -> Quiet | [QUIET] |
| 185 W (100–120 V), | |
| 175 W (200–240 V) | |
| Built-in speaker | 10 W monaural |
| Cabinet materials | Molded plastic |
| Filter | Included |
| Estimated filter maintenance cycle | Approx. 20,000 hours |
| Operation noise -> Normal | 36 dB [NORMAL] |
| Operation noise -> Eco | 36 dB [ECO] |
| Operation noise -> Quiet | 26 dB [QUIET] |
| Dimensions (W x H x D) | 399 mm x 115 mm x 348 mm (15 23/32˝ x 4 17/32˝ x 13 11/16˝ ) (not including protruding parts)399 mm x 133 mm x 348 mm (15 23/32˝ x 5 1/4˝ x 13 11/16˝ ) (with feet at shortest position) |
| Dimensions (W x H x D) -> Width (not including protruding parts) | 399 mm (15 23/32˝) |
| Dimensions -> Width (including protruding parts) | 399 mm (15 23/32˝) |
| Dimensions -> Height (not including protruding parts) | 115 mm (4 17/32˝) |
| Dimensions -> Height (including protruding parts) | 133 mm (5 1/4˝ ) |
| Dimensions -> Depth (not including protruding parts) | 348 mm (13 11/16˝) |
| Dimensions -> Depth (including lens) | 348 mm (13 11/16˝) |
| Weight | Approx. 6.5 kg (14.33 lbs) |
| Operating environment -> Operating temperature | 0–45 °C (32–113 °F) |
| Operating Environment -> Operating humidity (No condensation) | 20–80 % (no condensation) |
| Applicable software | Multi Monitoring & Control Software, Logo Transfer Software, Presenter Light Software for Windows, Wireless Projector App for iOS/Android |
