Sennheiser SR IEM G4 Wireless In-Ear Monitor Transmitter

USD 622.00USD 634.82 excl. Tax excl. Tax

Weight N/A
Choose Product Variant

SR IEM G4-A (516-558 MHz Ch26-Ch31)

,

SR IEM G4-B (626-668 MHz Ch40-Ch45)

,

SR IEM G4-C (734-776 MHz Ch54-Ch59)

,

SR IEM G4-D (780-822 MHz Ch59-Ch64)

,

SR IEM G4-E (823-865 MHz Ch65-Ch70)

,

SR IEM G4-G (566-608 MHz Ch33-Ch38)

,

SR IEM G4-A1

,

SR IEM G4-GB

SKU: N/A Category:
Description
Click to rate this post!
[Total: 0 Average: 0]

Sennheiser SR IEM G4 – Wireless In-Ear Monitor Transmitter for professional live sound applications

Sennheiser SR IEM G4 Wireless In-Ear Monitor Half-rack stereo transmitter in a full-metal housing with OLED display for full control delivering clarity along the whole frequency spectrum for daily use on stage with evolution wireless G4 In Ear Monitoring systems.

Specifications
Click to rate this post!
[Total: 0 Average: 0]
SR IEM G4
Frequency range
A1: 470-516 MHz
A: 516-558 MHz
GB: 606-648 MHz
G: 566-608 MHz
B: 626-668 MHz
C: 734-776 MHz
D: 780-822 MHz
E: 823-865 MHz
Dimensions
Approx. 202 x 212 x 43 mm
Compander
Sennheiser HDX
THD, total harmonic distortion
≤ 0.9 %
Weight
Approx. 980 g
Audio input
2x XLR-3/¼” (6.3 mm) jack combo socket, electronically balanced
Audio output
¼” (6.3 mm) stereo jack socket, balanced
Signal-to-noise ratio
> 90 dB
RF output power
switchable: Low: typ. 10 mW, Standard: typ. 30 mW, High: typ. 50 mW
Switching bandwidth
up to 42 MHz
Peak deviation
±48 kHz
Nominal deviation
±24 kHz
Modulation
Wideband FM stereo (MPX pilot tone)
Power supply
12 V DC
Current consumption
max. 350 mA
Max. Input voltage
+22 dBu
Transmission frequency
Max. 1680 frequencies, adjustable in 25 kHz steps, 20 frequency banks, each with up to 16 factory-preset channels, no intermodulation, 6 frequency banks with up to 16 programmable channels
AF frequency response
25 Hz to 15 kHz
Temperature Range
-10 °C to +55 °C
Frequency stability
±10 ppm
Antenna Output
BNC socket, 50 Ω
In The Box
Click to rate this post!
[Total: 0 Average: 0]
  • SR IEM G4 stereo transmitter
  • rod antenna
  • power supply
  • GA 3 rackmount set
  • quick guide
  • safety guide
  • manufacturer declaration sheet
