Teradek Ranger 4K 12G-SDI/HDMI Wireless TX/RX Set
USD 14,840.00 excl. Tax
Product Highlights
- Wireless 4K (2160p60) HDR video
- Zero-delay (< 1 ms)
- Uncompressed, 10-bit, 4:2:2 image quality
- Directional antenna for superb wireless performance
- Up to 3,000 ft. of wireless range or 5,000 ft. with panel antenna (included)
- 4.9 GHz to 6.0 GHz operation
- UNII-5 ready
- 40 MHz / 20 MHz channel bandwidths
- AES-256 encryption using RSA 1024 key exchange protocol
- Manual and automatic frequency selection
- Broadcast-capable
- Multicast-capable up to 6 receivers
| Weight | N/A |
|---|---|
| Choose Product Variants |
Ranger 4K Wireless TX/RX Set (Gold Mount) ,Ranger 4K Wireless TX/RX Set (V-Mount) |
This model has been discontinued
Description
Click to rate this post!
[Total: 0 Average: 0]
Teradek Ranger 4K Transmitter and Receiver Set(Gold Mount and V-Mount)
Teradek Ranger 4K TX/RX Set is a zero-delay (< 1 ms) wireless video system that transmits uncompressed 4K HDR video up to 5,000 ft. line of sight. With best-in-class performance in challenging RF conditions and a wide operating range from 4.9 GHz to 6.0 GHz, Ranger offers live productions the ultimate combination of industry-leading video quality and wireless integrity.
Uncompressed 4K HDR Video
10-bit, 4:2:2, Patented JSSC Technology
Flexible Operating Frequencies
4.9 to 6.0 GHz with 5 MHz Fine Tuning Intervals
UNII-5 Ready
Secure Video Transmission
AES-256 Encryption
Broadcast Capable
Transmit to Unlimited Receivers Simultaneously
Specifications
Click to rate this post!
[Total: 0 Average: 0]
| Ranger 4K Transmitter Specifications | |
|
Video |
|
| Video Inputs | 12G-SDI SMPTE 2082-1 standard / 75 Ω (BNC x 1) 1 x HDMI 2.0 Type-A receptacle |
| Video Outputs | 12G-SDI SMPTE 2082-1 standard / 75 Ω (BNC x 1) |
| Color Sampling | SDI: YCbCr 4:2:2, 10-bit HDMI: RGB 4:4:4, 8-bit | YCbCr 4:2:2, 10-bit |
| Delay Tx To Rx | <0.001sec |
| Input Cross Conversion | Yes, HDMI to SDI |
|
Bonding |
|
| Bonding | No |
|
Supported Resolutions |
|
| Supported Resolutions | 4Kp23.98/24/25/29.97/30/50/59.94/60 1080p23.98/24/25/29.97/30/50/59.94/60 1080psf23.98/24/25/29.97/30 1080i50/59.94/60 720p50/59.94/60 480p50 576p59.94/60 480i(NTSC)/576i(PAL) |
|
Video Processing |
|
| Video Compression | Uncompressed |
|
Audio Processing |
|
| Audio Format | 48kHz 24-bit PCM |
|
Inputs |
|
| Audio Input | Embedded SDI/HDMI Audio Input (2 Channel) |
|
Physical |
|
| Dimensions | 5.9” x 3.6” x 1.2” (149 x 91 x 30mm) |
| Weight | 19.1oz (544g) |
| Construction | Milled Aluminum(Chassis) and regulation-compliant PCB |
| Mountability | Multiple mounting options with 1/4″x20 and M3 holes |
|
Interfaces |
|
| Configuration Interfaces | OSD with Menu, Joystick Navigation |
| Switches | On/Off Switch |
| Recording Storage | Upgrade via Micro-USB |
| Mobile App | iOS and Android app configuration via Bluetooth |
| Desktop App | Launchpad application for OSX & Windows |
| Usb Interface Functionality | Bluetooth 5 LE |
|
Network |
|
| Wireless | Licensed Frequencies: 4.850 ~ 5.150 GHz 5.350 ~ 5.470 GHz 5.850 ~ 5.925 GHz Unlicensed Frequencies: 5.150 ~ 5.250 GHz (Non-DFS) 5.250 ~ 5.350 GHz (DFS) 5.470 ~ 5.725 GHz (DFS) 5.725 ~ 5.850 GHz (Non-DFS) *By using this product in the licensed frequencies, you acknowledge and agree to comply with all applicable regulations and rules, and to only operate this system in compliance with the applicable license requirements. |
| Rf Channel Selection | Auto, Manual Manual available for non-DFS Channels |
| Encryption | AES-256, RSA-1024 key exchange |
| Rf Power | 19 dbm EIRP (2 external 2dBi antennas) (<80mW transmit power) |
| RF Sensitivity | 1x Horizontal N-Type 2dBi antenna 1x Vertical N-Type 2dBi antenna |
| Range | Up to 5000 ft line of sight (using Panel Antenna on RX) |
| Unicast Multicast | Can connect one transmitter to up to 6 receivers |
| Noise Rejection | Can coexist with WiFi and 5GHz cordless phones Can operate up to 6 sets in same location |
|
Power |
|
| Power Input | 2-Pin Circular locking connector 7-28 VDC |
| Battery | Gold or V mount battery plate |
| Nominal Power Consumption | 19 Watts |
|
Environmental |
|
| Operating Temperature | 0-40℃ |
| Ranger 4K Receiver Specifications | |
|
Video |
|
| Video Outputs | 12G-SDI SMPTE 2082-1 standard / 75 Ω (BNC x 2) 1 x HDMI 2.0 Type-A receptacle |
| Color Sampling | SDI: YCbCr 4:2:2, 10-bit HDMI: RGB 4:4:4, 8-bit | YCbCr 4:2:2, 10-bit |
| Delay Tx To Rx | <0.001sec |
|
Bonding |
|
| Bonding | No |
|
Supported Resolutions |
|
| Supported Resolutions | 4Kp23.98/24/25/29.97/30/50/59.94/60 1080p23.98/24/25/29.97/30/50/59.94/60 1080psf23.98/24/25/29.97/30 1080i50/59.94/60 720p50/59.94/60 480p50 576p59.94/60 480i(NTSC)/576i(PAL) |
|
Video Processing |
|
| Video Compression | Uncompressed |
| Video Format Conversion Support | Yes, Framerate and Resolution Scaling |
|
Audio Processing |
|
| Audio Format | 48kHz 24-bit PCM |
|
Outputs |
|
| Audio Output | Embedded SDI/HDMI Audio Output (2 Channel) |
|
Physical |
|
| Dimensions | 133.74mm x 139.2mm x 30.10mm (5.3” x 5.5” x 1.2”) |
| Weight | 23 oz (656g) |
| Construction | Milled Aluminum(Chassis) and regulation-compliant PCB |
| Mountability | Multiple mounting options with 1/4″x20 and 3/8″x16 holes |
|
Network |
|
| Wireless | 5 External 2 dBi antennas (included) |
| Wireless | Licensed Frequencies: 4.850 ~ 5.150 GHz 5.350 ~ 5.470 GHz 5.850 ~ 5.925 GHz Unlicensed Frequencies: 5.150 ~ 5.250 GHz (Non-DFS) 5.250 ~ 5.350 GHz (DFS) 5.470 ~ 5.725 GHz (DFS) 5.725 ~ 5.850 GHz (Non-DFS) *By using this product in the licensed frequencies, you acknowledge and agree to comply with all applicable regulations and rules, and to only operate this system in compliance with the applicable license requirements. |
| Rf Channel Selection | Auto, Manual Manual available for non-DFS Channels |
| Encryption | AES-256, RSA-1024 key exchange |
| Rf Power | 17 dbm EIRP (one external 2dBi antenna) (<51mW transmit power) |
| Range | Up to 5000 ft line of sight (using Panel Antenna on RX) |
| Unicast Multicast | Can connect one transmitter to up to 6 receivers |
| Noise Rejection | Can coexist with WiFi and 5GHz cordless phones Can operate up to 6 sets in same location |
|
Power |
|
| Power Input | 2-Pin circular locking connector 6-28V DC |
| Battery | Gold or V mount battery plate |
| Nominal Power Consumption | 15 Watts |
|
Environmental |
|
| Operating Temperature | 0-40℃ |
