Yamaha VC4NW Ceiling Speaker
USD 96.00 excl. Tax
Yamaha VC8NW Ceiling Speaker
USD 158.00 excl. Tax
Yamaha VC6NW Ceiling Speaker
USD 125.00 excl. Tax
Product Highlights:
- 2-way system with 6.5-inch woofer and 0.8-inch tweeter, no back can
- Engineered for optimum BGM and voice reproduction
- No back can low-profile design allows installation in limited ceiling spaces
- Direct support for low-impedance or high-impedance connections
- 16Ω in low-impedance is advantageous when connecting multiple speakers in low impedance system
- Double-threaded speaker clamp screws for speedy tightening
- Paintable grilles with magnetic catches
- Black and white versions available
- 2.3 kg (5.1 lbs), Ø286 x D114 mm (Ø11-2/8” x D4-4/8”)
| Weight | N/A |
|---|---|
| Choose Product Variations |
VC6N Black ,VC6N White |
Description
Click to rate this post!
[Total: 1 Average: 5]
Yamaha VC6NW 6.5-Inch Low Profile Ceiling Speaker
The Yamaha VC6NW Ceiling Speaker is crafted to deliver high quality audio performance, ideal for background music (BGM) and voice projection in diverse settings. Equipped with a 2-way system featuring a 6.5-inch woofer and a 0.8-inch tweeter, this speaker guarantees a harmonious and crisp sound delivery across a broad spectrum of frequencies.
Notably, its no back can design enables hassle-free installation, even in tight ceiling spaces. This sleek profile not only streamlines the installation process but also ensures the speaker blends seamlessly into its surroundings while maintaining peak performance.
Versatility is a standout feature of the VC6NW. It supports both low-impedance and high-impedance connections, providing users with flexibility to accommodate different audio setups and needs. With a nominal impedance of 16Ω in low-impedance mode, it excels in connecting multiple units in a low-impedance system, ensuring efficient power distribution and consistent performance.
Engineered for convenience, the VC6NW boasts double-threaded speaker clamp screws for quick tightening during installation, reducing setup time and effort. Additionally, its paintable grilles with magnetic catches allow users to customize the appearance to complement the installation environment’s décor.
Available in black and white versions, the VC6NW offers aesthetic versatility to match various preferences and interior designs. Despite its powerful performance, it remains lightweight at 2.3 kg (5.1 lbs) with dimensions of Ø286 x D114 mm (Ø11-2/8” x D4-4/8”), making it easy to handle and install.
Recommended applications for the Yamaha VC6NW Ceiling Speaker include shopping malls, office buildings, restaurants, healthcare facilities, and transportation terminals, where wide coverage areas with multiple speakers are often necessary.
In conclusion, the Yamaha VC6NW Ceiling Speaker blends top-notch audio reproduction, flexible connectivity options, and user-friendly features, making it an ideal choice for a wide array of applications, suitable for both commercial and residential environments, the VC6NW is the perfect choice where superior sound quality and effortless integration are essential.
To view more Yamaha Products
Related Product:
VC Series Product:
- Yamaha VC8NW Ceiling Speaker
- Yamaha VC4NW Ceiling Speaker
- Yamaha VC8W Ceiling Speaker
- Yamaha VC4W Ceiling Speaker
- Yamaha VC6W Ceiling Speaker
VXC Series Product:
Speaker Types:
Indhu UC added on 13 Mar 24
Specifications
Click to rate this post!
[Total: 1 Average: 5]
General Specifications:
- Speaker type: 2way Coaxial type (without backcan)
- Frequency range (-10dB): 63 Hz – 20 kHz (Half-space: 2π)
- Nominal coverage: 120° conical (Half-space: 2π)
- Components – LF: 6.5” Cone
- HF: 0.8″ Soft dome
Power rating:
- NOISE: 25 W
- PGM: 50 W
- PEAK: 100 W
- Nominal impedance: 16 Ω
- Transformer taps 100V: 12 W, 6 W, 3 W
- Transformer taps 70V: 12 W, 6 W, 3 W, 1.5 W
- SPL- Sensitivity (1W; 1m on axis): 89 dB SPL (Half-space:2π)
- Peak (Calculated): 109 dB SPL (Calculated, 1 m)
- I/O connectors: Push terminal (WAGO 294 /2 pin) × 1, Wire size : Solid conductor Min. AWG18 (0.75 sq) / Max. AWG12 (3.5 sq), Standard conductor Min. AWG18 (0.75 sq) / Max. AWG14 (2 sq)
- Protection circuit Load protection: Full-range power limiting to protect network and transducers
- Finish: VC6NB: Black (approx. Munsell N3), VC6NW: White (approx. Munsell N9.3)
Dimensions:
- Diameter: 286 mm (11 – 2/8″)
- D: 114 mm (4 – 4/8″)
- Net weight: 2.3 kg (5.1 lbs)
- Cutout size: Ø247 mm (Ø9 – 3/4″)
- Required ceiling board thickness: 2 mm – 37 mm
- Accessories: C-Ring, Tile Rails x 2, Grille, Safety wire, Cutout template, Owner’s Manual
- Packaging: Single package
- Certificate: CE, RoHS
