AVMATRIX SC2030 HDMI/SDI Scaling Cross Converter

Connections

Video Input

1×SD/HD/3G-SDI
1×HDMI type A

Video Output
2×SD/HD/3G-SDI
1×HDMI type A

Analog Audio Input: 1×1/8″ (3.5mm) jack

Updates: Micro USB

Standards

HDMI Input Format Support
1080p 60/59.94/50
1080p 30/29.97/25/24/23.98/23.976
1080i 60/59.94/50
720p 60/59.94/50
720p 30/29.97/25/24/23.98
576p 50,576i 50
480i 60/59.94

SDI Input Format Support
1080p 60/59.94/50（Level A&B）
1080p 30/29.97/25/24/23.98
1080PsF 30/29.97/25/24/23.98
1080i 60/59.94/50
720p 60/59.94/50
720p 30/29.97/25/24/23.98
625i 50, 525i59.94

SDI/HDMI Output Format Support
1080p 60/59.94/50
1080p 30/29.97/25/24/23.98
1080i 60/59.94/50
720p 60/59.94/50

HDMI Color Space and Precision
RGB 4:4:4
YUV 4:2:2
YUV 4:4:4

SDI Compliance
SMPTE 292M
SMPTE 259M
SMPTE 424M

SDI Color Space and Precision: YUV 4:2:2
SDI Video Rate: SD/HD/3G-SDI

Power

Power: Micro USB
Threaded locking connector
Power Consumption: 4W
Voltage Range: USB 5V, DC 6-23

Physical Specifications

Dimension: 125.5×104×24.5mm
Net Weight: 485g
Gross Weight: 1270g
Warranty: 3 Year Limited Manufacturer’s Warranty

Environmental Specifications

Operating Temperature: -20℃~60℃
Storage Temperature: -30℃~70℃
Relative Humidity: 0%~90% non-condensin

• SC2030 (SDI/HDMI Cross Converter)
• 2pcs Mounting Brackets
• DC 12V Universal Power Supply with International Socket Adapters
