Panasonic AK-SHB800GJ 8K ROI Multi Purpose Camera

Panasonic AK-SHB800GJ 8K ROI Multi-Purpose Camera LC Connector Model

Panasonic AK-SHB800GJ 8K ROI camera serves as four HD cameras to improve operational efficiency and reduce operating costs in live events and sports applications.

A multi-camera system can be configured by linking the cropping operations of multiple cameras. The wide-angle distortion correction function provides natural-looking crops.

FEATURES

8K ROI Camera

• Smart Studio Technology
• 8K ROI Camera System Output Signal Format in Each System Mode

8K ROI Camera Smart Studio Technology

• Features an 8K full-size CMOS image sensor.
• Up to four separate HD videos can be cropped from a high-resolution, wide-angle 8K image, and each cropped image can be panned, tilted, and zoomed individually using recommended remote controllers.
• Portrait, horizontal linking, vertical linking, and 4-frame cross-linking (4K) cropping frame variations.
• An automatic wide-angle distortion correction function removes, in real-time, distortion of images cropped from the periphery, thus realizing natural-looking images.
• Tally lamps (red or green frames in the corner of the cropping frames; see the diagram below.) can be displayed.
• Up to eight 8K Multi-Purpose Camera, units can be linked for cropping a maximum of 32 different HD videos.
• Compatible with the remote camera controller (AW-RP150GJ)*1. Pan, tilt, or zoom the cropped frames using the joystick. You can also select the cropped frames.
• The individual picture settings for each cropping area are possible using a Remote Operation Panel (optional, AK-HRP1000GJ*2).
• Framing Control Software*3 features an easy-to-use GUI operation.
• The compact, lightweight, Multi-Purpose Camera allows a space-saving, flexible setup at any desired angle.
• PTZ Camera (AW-UE150W/K) can be linked to an 8K ROI camera to allow a single operator to shoot from multiple angles.

Support Efficient Operation

• Four HD Videos Can Be Cropped from within An 8K Image
• Portrait, Horizontal Linking, Vertical Linking, and 4-frame Cross-linking (4K) Cropping Frame Variations

Four HD Videos Can Be Cropped from within An 8K Image

ROI stands for Region of Interest. An 8K ROI camera can be set with a maximum of four crop areas to obtain an HD image from each of the crop areas. Pan, tilt and zoom operations can be used on each crop area, so a single 8K ROI camera serves as four HD cameras. It improves acquisition efficiency in live and sports applications. Panasonic AK-SHB800GJ 8K ROI camera contributes to the reduction of camera setup, relocation, and transport costs. It also eliminates the need to take up audience seats for the setup of multiple cameras.

Application Example of the 8K ROI Camera System (1 Camera, Live Stage Recording)

The 8K Multi-Purpose Camera is set up in a fixed position. The four crop areas can be individually controlled for pan, tilt, and zoom. Moreover, for example, long shots (yellow frame) and close-up (cyan frame) can be linked in operation.

Video Production Functions

• Linkage of Multi-camera/Multi-angle Crop Frames
• Automatic Real-time Correction of Wide-angle Distortion
• Framing Control Software – Software Key AK-SFC101

Linkage of Multi-camera/Multi-angle Crop Frames

A multiple of 8K Multi-Purpose Camera units or PTZ Camera (AW-UE150) (maximum of 8 units) can be connected and operated as one integrated system. By setting one crop area in the main frame and linking it to other crop areas, pan, tilt, and zoom on the multiple crop images operate in link with the panning, tilting, and zooming on the main frame. This improves operational efficiency in multi-camera/multi-angle recording or broadcasting.

Application Example of the 8K ROI Camera System (3 Cameras, Basketball Game Broadcasting)

Automatic Real-time Correction of Wide-angle Distortion

This function automatically corrects, in real-time, wide-angle distortion of images cropped from the image periphery away from the center image. This results in natural-looking videos as if the camera images were individually panned or tilted.

Portrait, Horizontal Linking, Vertical Linking, and 4-frame Cross-linking (4K) Cropping Frame Variations

It is possible to cut out images with portraits (vertical) for displaying on a vertical display like a smartphone, horizontal linking of multiple frames, vertical linking, and 4-frame cross-linking (4K) as cutout variations.

Framing Control Software – Software Key AK-SFC101

8K ROI (Region Of Interest) Camera System Software. Single 8K Multi-Purpose Camera serves as four HD cameras to improve operating efficiency and reduce operating costs in live events and sports applications.

• Up to four separate HD videos can be cropped from an 8K image.
• Each cropped image can be panned, tilted, and zoomed individually.
• Portrait, horizontal linking, vertical linking, and 4-frame cross-linking (4K) cutout frame variations.
• Tracing memory function that records and reproduces the position, size, and movement of the cropped frame. Save up to 100 memories per cropped frame.
• Up to eight 8K Multi-Purpose Camera, units can be linked for cropping a maximum of 32 different HD videos.
• By linking the panning, tilting, and zooming of several cropping frames, you can conduct multi-camera and multi-angle operations with fewer crews.
• An easy-to-use GUI and joystick controller simplifies operation.

Software Key AK-SFC101

Software keys to activate Framing Control Software and add functions.
