Panasonic PT-LMW420 Revitalize Communication with 4,000-lm-class WUXGA Portable Laser Projector
Product Highlights:
- Effortless Projection Anywhere, Anytime
- 4,200 lumens brightness output
- WUXGA resolution for sharp visuals
- Compact and lightweight design
- 20,000-hour laser light source
- 1.2x zoom with flexible throw
- Filterless, dust-resistant design
- Ideal for education and business
Description
Panasonic PT-LMW420 4,200-Lumens WUXGA Portable Laser Projector with 20,000-Hours Light Source
The Panasonic PT-LMW420 is a compact, portable WUXGA laser projector designed for clear, bright, and reliable performance in classrooms, conference rooms, and other collaborative environments. Delivering up to 4,200 lumens of brightness, this projector ensures vivid images and sharp text even in well-lit spaces. It’s built to streamline professional presentations with reliable laser performance, simplified setup, and low-maintenance operation.
Panasonic PT-LMW420 Laser Projector offers High-Brightness Laser Performance
The PT-LMW420 offers 4,200 lumens of brightness and a high contrast ratio of 3,000,000:1, enabling crisp visuals with rich detail. Its WUXGA resolution (1920 x 1200) ensures clear projection of fine text and detailed graphics, ideal for educational, business, and signage applications.
Compact and Lightweight
This projector is designed for flexibility and portability. Weighing approximately 4.5 kg (9.9 lbs), the PT-LMW420 is easy to carry and quick to install. The small footprint supports discreet placement on a desk, ceiling mount, or AV cart, making it suitable for dynamic presentation environments.
Long-Lasting Laser Light Source
The laser light engine delivers up to 20,000 hours of maintenance-free operation, minimizing disruptions and lowering total cost of ownership. The sealed optical unit and filter less design help reduce dust intrusion, making it highly reliable even in classrooms or public areas with variable air quality.
1.2x Zoom and Flexible Throw Ratio
With a 1.2x zoom lens and throw ratio of 1.28–1.54:1, the projector can be installed at a flexible distance from the screen, supporting various room sizes. Keystone correction and screen adjustment tools simplify alignment on irregular surfaces or off-center placements.
HDMI and Versatile Connectivity
The PT-LMW420 supports HDMI input, D-sub (VGA), USB, and RS-232C, ensuring compatibility with a wide range of devices—from laptops and media players to control systems. The HDMI CEC function allows basic control of connected devices through a single remote, improving operational efficiency.
Quick Start, Instant Off, and Quiet Operation
The projector powers on in just one second and powers off instantly with no cooldown time, enhancing usability in fast-paced environments. With a low operating noise of just 25 dB (in Quiet Mode), it ensures minimal distraction during meetings or lessons.
Panasonic PT-LMW420 Laser Projector Designed for Education and Business
Optimized for modern teaching and corporate settings, the PT-LMW420 is ideal for schools, offices, and public venues. Its reliable laser technology, compact build, and excellent image quality help improve communication and engagement in collaborative spaces.
To view more Panasonic Products
View more LCD and Laser Projectors
Projector Types
Specifications
| Panasonic PT-LMW420 Laser Projector | |
| Projector type | LCD projectors |
| Display method | Transparent LCD panel (x 3, R/G/B) |
| Display Device -> Panel size | 16.3 mm (0.64 in) diagonal (16:10 aspect ratio) |
| Display Device -> Drive method | Active-matrix method |
| Display Device -> Number of pixels | 1,024,000 (1280 x 800) pixels |
| Light source | Laser diodes |
| Light output | 4,200 lm |
| Light output (ANSI) | 4,200 lm |
| Time until light output declines to 50 % -> NORMAL | 20,000 hours [NORMAL] |
| Time until light output declines to 50 % -> ECO | 24,000 hours [ECO] |
| Time until light output declines to 50 % -> QUIET | 20,000 hours [QUIET] |
| Resolution | WXGA (1280 x 800 pixels) |
| Contrast Ratio (typ.) | 3,000,000:1 (Full On/Full Off)(When [PICTURE MODE] is set to [DYNAMIC] and [DYNAMIC CONTRAST] is set to [1].) |
| Screen size (diagonal) | 0.76–7.62 m (30–300 in), 16:10 aspect ratio |
| Center-to-corner zone ratio | 85% |
| Lens | 1.2x manual zoom (throw ratio: 1.36–1.64:1), manual focus lens, F 1.61–1.76, f 19.1–23.0 mm |
| Digital Zoom Extender | Throw ratio: 1.36–2.05:1 (Corresponding value. When used together with optical zoom.) |
| Keystone correction range | Vertical: ±35 ° (Auto, Manual), |
| Horizontal: ±35 ° (Manual) | |
| Installation | Ceiling/floor, front/rear, free 360-degree installation |
| Terminals -> HDMI IN | HDMI 19-pin x 2 (Compatible with HDCP 1.4, Deep Color, 4K/30p signal input), CEC supported |
| Terminals -> COMPUTER IN（D-SUB 15pin） | D-sub 15-pin (female) x 1 (RGB/YPBPR/YCBCR) |
| Terminals -> COMPUTER OUT（D-SUB 15pin） | D-sub 15-pin (female) x 1 (RGB/YPBPR/YCBCR) |
| Terminals -> AUDIO IN(M3 Stereo Mini Jack) | M3 stereo mini-jack x 2 |
| Terminals -> AUDIO OUT(M3 Stereo Mini Jack) | M3 stereo mini-jack x 1 |
| Terminals -> SERIAL IN | D-sub 9-pin (female) x 1 for computer control (RS-232C compliant) |
| Terminals -> LAN | RJ-45 x 1 for network control, 10Base-T, 100Base-TX |
| Terminals -> USB TYPE A | USB connector (Type A) x 1 for Memory Viewer function, optional AJ-WM50 Series Wireless Module,power supply (DC 5 V, maximum 2 A) |
| Protocol versions | IPv4, IPv6 |
| Power supply | AC 100 V–240 V, 50/60 Hz |
| Maximum power consumption | 230 W |
| On-mode power consumption(Operating mode) -> Normal | [NORMAL] 205 W (100–240 V), 195 W (200–240 V) |
| On-mode power consumption(Operating mode) -> Eco | [ECO] 155 W (100–240 V), 145 W (200–240 V) |
| On-mode power consumption(Operating mode) -> Quiet | [QUIET] 150 W (100–240 V), 145 W (200–240 V) |
| Built-in speaker | 10 W monaural |
| Cabinet materials | Molded plastic |
| Filter | Included |
| Estimated filter maintenance cycle | Approx. 20,000 hours |
| Operation noise -> Normal | 33 dB [NORMAL] |
| Operation noise -> Eco | 33 dB [ECO] |
| Operation noise -> Quiet | 23 dB [QUIET] |
| Dimensions (W x H x D) | 349 mm x 105 mm x 309 mm (13 3/4˝ x 4 1/8˝ x 12 5/32˝ ) (with feet at shortest position) |
| Dimensions -> Width (including protruding parts) | 349 mm (13 3/4˝) |
| Dimensions -> Height (including protruding parts) | 105 mm (4 1/8˝) |
| Dimensions -> Depth (including lens) | 309 mm (12 5/32˝) |
| Weight | Approx. 4.2 kg (9.26 lbs) |
| Operating environment -> Operating temperature | 0–45 °C (32–113 °F) |
| Operating Environment -> Operating humidity (No condensation) | 20–80 % (no condensation) |
| Applicable software | Multi Monitoring & Control Software, Projector Network Setup Software, Logo Transfer Software,Presenter Light Software for Windows, Wireless Projector App for iOS/Android |
| Control function via LAN | PJLink [Class 2], Crestron Connected, AMX Device Discovery |
