Blackmagic Micro Converter SDI to HDMI 12G

Name: Blackmagic Micro Converter SDI to HDMI 12G
Rating: 5 (4 reviews)

USD 143.00 – USD 154.00 excl. Tax excl. Tax

Compact, rugged design for portability
Supports DCI/UHD 4K60 input/output
12G-SDI input and loop output available
USB Type-C power and firmware update capabilities
Handles embedded audio seamlessly
LED indicators for quick operational insights

Weight	N/A
Choose Product Variant	Micro Converter SDI to HDMI 12G , Micro Converter SDI to HDMI 12G wPSU

Choose Product Variant

SKU: N/A Category: Signal Converters

Description

Click to rate this post!

[Total: 4 Average: 5]

Blackmagic Design Micro Converter SDI to HDMI 12G

The Blackmagic Design Micro Converter SDI to HDMI 12G is engineered for versatile connectivity, marrying SDI source devices like cameras or computers with high-definition HDMI display systems. This device stands out due to its superb compactness and durability, making it ideal for professional use in various settings, including studios, live events, and on-location shoots.

Compact and Rugged Design

Quick Look at Blackmagic Micro Converters

This converter is crafted with a robust metal housing that withstands the rigors of professional environments. Its size is notably pocket-friendly, allowing easy transport without sacrificing functionality. The rugged connectors enhance longevity, ensuring reliable performance even under demanding conditions. Furthermore, the device’s LED status indicators for power and signal enhance operational awareness, reducing downtime during critical moments.

Advanced Input/Output Configuration

The Micro Converter boasts an impressive array of I/O options:

12G-SDI Input: Capable of accepting high-definition video signals to deliver the highest quality possible.
HDMI Output: Connects directly to HDMI displays or projectors, ensuring compatibility with a wide range of modern devices.
12G-SDI Loop Output: This feature allows for easy daisy-chaining of multiple devices, making this converter suitable for complex setups.

Resolution Support

This converter offers extensive resolution compatibility, supporting input and output up to DCI/UHD 4K at 60 frames per second. Whether working with traditional broadcast formats like NTSC and PAL or the latest cinema standards, the device delivers seamless integration between fluctuating video resolutions and frame rates.

Embedded Audio Handling

Audio performance is equally critical, and this converter excels in managing audio signals. It supports embedded audio from the SDI input and transmits it alongside video via the HDMI output, minimizing the need for additional audio devices. This feature simplifies setup and reduces clutter, making it a practical choice for live broadcasts and recordings.

Timecode Support and SDI Re-Clocking

Timecode support ensures synchronization across devices, which is vital in multi-camera setups and live events. The built-in SDI re-clocking function enhances signal stability over long cable runs, a significant advantage when transmitting high-quality video across extensive distances. This feature mitigates signal degradation, ensuring consistent output quality.

USB Type-C Connectivity

Versatile USB Type-C connectivity makes powering the device straightforward. Users can draw power from compatible components such as monitors, laptops, or dedicated USB power supplies. This flexibility streamlines operation by minimizing the number of cables and power sources needed in a setup. Additionally, users can perform firmware updates and device configurations through the USB Type-C port using Windows or macOS computers, ensuring that the converter remains up to date with the latest features and improvements.

Supported Operating Systems

The Micro Converter is compatible with several operating systems:

macOS 10.15 Catalina and later
Windows 10 (64-bit only)

This wide compatibility ensures that users can integrate the Micro Converter into various workflows, adapting it to different environments without compatibility concerns.

LED Indicators for Enhanced Monitoring

The converter offers real-time feedback on operational status and is equipped with LED indicators for both video and power signals. This feature provides peace of mind, allowing users to quickly detect any issues, considerably improving working efficiency, especially in fast-paced environments.

The Blackmagic Micro Converter SDI to HDMI 12G is a professional-grade audio and video connectivity solution. Its rugged design, high-resolution support, and flexible operation make it a must-have in any media production toolkit.

To view more Blackmagic products

Another Website:

Micro Converter SDI to HDMI 12G

Micro Converter SDI To HDMI

Read Our Blog:

Blackmagic Broadcast Converters: Micro, Mini, and Teranex Mini Series Explained

M by Indhu 27 Feb23
Add-R-Ind-29.11.23
Add-T-SS-20/2/24
Indhu-NC-2/Oct24
SS-RMlink7 Oct24
IM-AV-19Dec24
IM-AV-26Dec24
IM-UT-20Jan25

Specifications

Click to rate this post!

[Total: 4 Average: 5]

Connections
SDI Video Inputs	1
SDI Video Outputs	1 x loop out
HDMI 2.0 Video Outputs	1 x type A.
SDI Rates	270Mb, 1.5G, 3G, 6G, 12G.
Multi Rate Support	Auto-detection of SD, HD, 2K, Ultra HD and 4K.
Updates, Configurations and Power	USB Type‑C.
Standards
SD Video Standards	525i59.94 NTSC, 625i50 PAL
HD Video Standards	720p50, 720p59.94, 720p60 1080p23.98, 1080p24, 1080p25, 1080p29.97, 1080p30, 1080p47.95, 1080p48, 1080p50, 1080p59.94, 1080p60 1080PsF25, 1080PsF29.97, 1080PsF30 1080i50, 1080i59.94, 1080i60
2K Video Standards	2Kp23.98 DCI, 2Kp24 DCI, 2Kp25 DCI, 2Kp29.97 DCI, 2Kp30 DCI, 2Kp47.95 DCI, 2Kp48 DCI, 2Kp50 DCI, 2Kp59.94 DCI, 2Kp60 DCI 2KPsF25 DCI, 2KPsF29.97 DCI, 2KPsF30 DCI
Ultra HD Video Standards	2160p23.98, 2160p24, 2160p25, 2160p29.97, 2160p30, 2160p47.95, 2160p48, 2160p50, 2160p59.94, 2160p60
4K Video Standards	4Kp23.98 DCI, 4Kp24 DCI, 4Kp25 DCI, 4Kp29.97 DCI, 4Kp30 DCI, 4Kp47.95 DCI, 4Kp48 DCI, 4Kp50 DCI, 4Kp59.94 DCI and 4Kp60 DCI.
SDI Compliance	SMPTE 259M, SMPTE 292M, SMPTE 296M, SMPTE 424M, SMPTE 425M, SMPTE 2081-1, SMPTE 2081-10, SMPTE 2082-1, SMPTE 2082-10, SMPTE 2084 and SMPTE 2108-1
SDI Video Rates	SDI video connections are switchable between standard definition, 720p, 1080i, 1080p, 2K DCI, Ultra HD and 4K DCI.
SDI Colour Precision	4:2:2. A 17-point LUT can be loaded via the software utility for calibrating or improving monitor colour.
SDI Colour Space	YUV
SDI Auto Switching	Automatically detects SD, HD level A or B for 3G‑SDI, 2K DCI, Ultra HD and 4K DCI.
HDMI Video Standards	525i59.94 NTSC, 625i50 PAL 720p50, 720p59.94, 720p60 1080p23.98, 1080p24, 1080p25, 1080p29.97, 1080p30, 1080p47.95, 1080p48, 1080p50, 1080p59.94, 1080p60 1080i50, 1080i59.94, 1080i60 2160p23.98, 2160p24, 2160p25, 2160p29.97, 2160p30, 2160p47.95, 2160p48, 2160p50, 2160p59.94, 2160p60 4Kp23.98 DCI, 4Kp24 DCI, 4Kp25 DCI, 4Kp29.97 DCI, 4Kp30 DCI, 4Kp47.95 DCI, 4Kp48 DCI, 4Kp50 DCI, 4Kp59.94 DCI and 4Kp60 DCI.
HDMI Colour Precision	4:2:2. A 17-point LUT can be loaded via the software utility for calibrating or improving monitor colour.
HDMI Colour Space	YUV
Settings Control	Via MacOS and Windows software utility connected by USB.
Operating Systems	Mac 10.15 Catalina, Mac 11.1 Big Sur or later. Windows 10, 64-bit.
Software	Internal software upgrade via USB.
Power Requirements
Power Consumption	4W max.
Operational Voltage Range	4.4V to 5.25V DC
Environmental Specifications
Operating Temperature	0° to 40° C (32° to 104° F)
Storage Temperature	-20° to 60° C (-4° to 140° F)
Relative Humidity	0% to 90% non-condensing
Warranty	3-Year Limited Manufacturer’s Warranty.
